1 PCS used Emerson Inverter EV5000-4T0150G #LYQ007
Original Factory Precision Parameters (Model: Emerson Inverter EV5000-4T0150G)
|
Parameter Category
|
Parameter Name
|
EV5000-4T0150G Specification
|
|
Basic Information
|
Product Model
|
EV5000-4T0150G; Emerson Genuine Original General-Purpose Inverter, 100% unused and unrefurbished genuine parts
|
|
Manufacturer Standard
|
Manufactured by Emerson; Compliant with ISO 9001, CE, RoHS, GB/T 12668.2-2002 Standards; Conforms to Emerson Internal Technical and Quality Norms
|
|
|
Product Application
|
Industrial Automation, Water Supply and Drainage, Fan and Pump Control, Conveyor Systems, Machine Tools, Metallurgical Equipment, Chemical Machinery, Building Ventilation and Air Conditioning
|
|
|
Core Electrical Parameters
|
Input Voltage
|
Three-phase AC 380V~440V; Voltage Tolerance: ±15%; Frequency: 50Hz/60Hz (Automatic Adaptation); Suitable for Industrial Three-phase Power Supply Scenarios
|
|
Rated Output Power
|
15kW (20HP); Continuous Output Power, Consistent with Factory Calibration Standards, Ensure Long-term Stable Operation
|
|
|
Rated Output Current
|
32A; Rated Working Current, ±1% Precision, Ensure Matching with 15kW Three-phase Asynchronous Motors
|
|
|
Output Frequency Range
|
0.00~600.00Hz; Stepless Speed Regulation, Precision ±0.01Hz, Adapt to Different Speed Demand Scenarios
|
|
|
Frequency Resolution
|
0.01Hz (0.00~99.99Hz); 0.1Hz (100.0~600.0Hz); High Resolution, Ensure Precise Speed Control
|
|
|
Output Voltage
|
0~Input Voltage; Proportional Adjustment with Output Frequency (V/F Control Mode), Ensure Stable Motor Operation
|
|
|
Efficiency
|
≥96% (Rated Load); High Energy-saving Efficiency, Reduce Industrial Power Consumption, Meet Energy-saving Standards
|
|
|
Control & Speed Regulation Parameters
|
Control Mode
|
V/F Control (Open-loop); Optional Vector Control (Closed-loop); Flexible Switching, Adapt to Different Load Characteristics
|
|
Torque Control
|
Automatic Torque Boost; Torque Compensation at Low Frequency, Ensure Motor Torque Stability at 0.5Hz
|
|
|
Acceleration/Deceleration Time
|
0.01~3600.00s (Adjustable); Separate Acceleration and Deceleration Time Setting, Avoid Motor Impact
|
|
|
V/F Curve
|
4 Modes Optional: Linear, Square, Exponential, User-defined; Adapt to Fan, Pump, Constant Torque and Other Loads
|
|
|
Speed Regulation Precision
|
≤±0.5% (V/F Open-loop); ≤±0.1% (Vector Closed-loop); High Precision Speed Regulation, Ensure Production Stability
|
|
|
Multi-segment Speed
|
Up to 16 Segments Speed Control; Support Step Speed Regulation, Adapt to Intermittent Production Scenarios
|
|
|
Protection & Safety Parameters
|
Overcurrent Protection
|
Instantaneous Overcurrent: 150% Rated Current, 0.1s Trip; Continuous Overcurrent: 120% Rated Current, 1min Trip; Prevent Inverter and Motor Damage
|
|
Overvoltage Protection
|
DC Bus Overvoltage Protection: ≥800V (380V Input); Automatic Deceleration or Trip, Avoid Component Damage Caused by Voltage Surge
|
|
|
Overload Protection
|
150% Rated Load, 60s Trip; 120% Rated Load, 180s Trip; Protect Motor from Overload Burning
|
|
|
Overheating Protection
|
Inverter Internal Temperature ≥85℃, Alarm; ≥90℃, Trip; Equipped with High-efficiency Heat Dissipation Fan, Ensure Stable Temperature Operation
|
|
|
Undervoltage Protection
|
DC Bus Undervoltage Protection: ≤450V (380V Input); Alarm and Trip When Input Voltage is Too Low, Avoid Abnormal Operation
|
|
|
ESD Protection
|
±8kV (Contact), ±15kV (Air); Effectively Protect the Inverter from Static Damage, Ensure Stable Operation in Electronic Manufacturing Environments
|
|
|
Other Protections
|
Motor Overheating Protection (PTC Input), Short Circuit Protection, Phase Loss Protection, Ground Fault Protection; Comprehensive Safety Guarantee
|
|
|
Environmental & Structural Parameters
|
Operating Temperature
|
-10°C ~ 50°C; Derating 1% per °C When Exceeding 40°C; Adapt to Various Industrial Working Environments
|
|
Storage Temperature
|
-20°C ~ 60°C; Stable Storage Performance, No Performance Degradation After Long-term Storage in Warehouse or Transportation
|
|
|
Relative Humidity
|
5% ~ 95% (Non-Condensing); Resisting Humid Industrial Environments, No Short Circuit or Malfunction Risk
|
|
|
Structure Material
|
Industrial-Grade Aluminum Alloy Shell; Anti-Corrosion, Anti-Oxidation, High Mechanical Strength, Dust-Proof Design (IP20), Suitable for Cabinet Installation
|
|
|
Interface & Compatibility Parameters
|
Control Interface
|
Digital Input: 6 Channels (Optically Isolated); Analog Input: 2 Channels (0~10V/4~20mA); Digital Output: 2 Channels; Convenient for External Control
|
|
Communication Interface
|
Standard RS485 Interface; Support Modbus RTU Communication Protocol; Realize Remote Monitoring and Control, Easy for System Integration
|
|
|
Motor Compatibility
|
Suitable for Three-phase Asynchronous Motors with Rated Power 15kW, Rated Voltage 380V, Rated Current ≤32A; Excellent Matching Performance
|
