1 PCS new Teledyne e2v Line Scan Camera EV71YC4MCL8005-BA0#LYQ007
1 PCS new Teledyne e2v Line Scan Camera EV71YC4MCL8005-BA0#LYQ007
| Parameter Category | Parameter Name | Specification |
|---|---|---|
| Basic Identification | Model Number | EV71YC4MCL8005-BA0 |
| Basic Identification | Product Series | ELIIXA+ 8k/4k CL Multi-Line Monochrome CMOS Camera |
| Basic Identification | Camera Link Configuration | Base / Medium (4×85 MHz or 2×85 MHz) |
| Basic Identification | Color Type | Monochrome |
| Sensor Core | Resolution (Active Lines) | 4×8192 pixels (5 μm) / 2×4096 pixels (10 μm); 2k pixels (20 μm, 4×4 binning) |
| Sensor Core | Pixel Size | 5×5 μm (8k mode); 10×10 μm (4k mode) |
| Sensor Core | Number of Active Lines | 4 (8k) / 2 (4k) |
| Sensor Core | Full Well Capacity | 27,300 electrons (2S/4S mode, MultiGain 1/2) |
| Performance | Maximum Line Rate (8k/4k) | 40 kHz / 80 kHz (Camera Link Medium) |
| Performance | Maximum Line Rate (8k/4k) | 20 kHz / 40 kHz (Camera Link Base) |
| Performance | Bit Depth | 8, 10, 12 bits (programmable) |
| Performance | Response (Broadband) | 450 LSB/(nJ/cm²) (max pixel rate, min gain) |
| Performance | Response Non-Linearity | ≤ 0.3% (max pixel rate, min gain) |
| Performance | PRNU HF (Max) | 3% |
| Performance | Dynamic Range (1S/2S/4S) | 67.6 / 70.7 / 68.7 dB |
| Performance | Trigger Modes | Free Run, External Trigger, External ITC |
| Interface | Data Interface | Camera Link (Hirose HR10A-7R-6PB male) |
| Interface | Data Rate | Up to 4×85 MHz (Medium); 2×85 MHz (Base) |
| Power | Supply Voltage | Single 12–24 VDC |
| Power | Power Dissipation | < 7.5 W (Camera Link) |
| Power | Inrush Current | Typical peak 1 A (≤ 2 s) |
| Mechanical | Dimensions (W×H×L) | 125 × 60 × 35 mm |
| Mechanical | Net Weight | 360 g |
| Mechanical | Lens Mount | F-Mount, T2, M42×1 |
| Mechanical | Sensor Alignment | ±100 μm |
| Mechanical | Sensor Flatness | 50 μm |
| Environmental | Operating Temperature | 0–55 °C (front face); 0–70 °C (internal) |
| Environmental | Storage Temperature | -40–70 °C |
| Environmental | Regulatory Compliance | CE (EN50081-2, EN61000-6-2), FCC Part 15 (Class A), RoHS 2011/65/EU |
| Functional Features | Programmable Controls | Analog gain (up to 12 dB), offset (-4096 to +4096 LSB), flat field correction, LUT |
| Functional Features | Multi-Line Modes | 1S, 2S, 4S (summation); binning (1/2 lines for 4k) |
