1 PCS new TELEDYNE E2V Line Scan Camera EV71YC4MCL1605-BA1 #LYQ007
1 PCS new TELEDYNE E2V Line Scan Camera EV71YC4MCL1605-BA1 #LYQ007
| Parameter Category | Parameter Name | EV71YC4MCL1605-BA1 Specification |
|---|---|---|
| Basic Information | Product Model | EV71YC4MCL1605-BA1Imaging Teledyne e2v |
| Product Family | ELiiXA+ 16K/8K Mono CMOS Multi-Line CameraImaging Teledyne e2v | |
| Sensor Type | CMOS, Multi-Line (4 lines)Imaging Teledyne e2v | |
| Resolution | 4 × 16384 Pixels (16K)Imaging Teledyne e2v | |
| Pixel Size | 5 µm × 5 µmImaging Teledyne e2v | |
| Color Mode | Monochrome (Mono) | |
| Core Imaging Parameters | Max Line Rate | 16K: 50 kHz; 8K: 100 kHzImaging Teledyne e2v |
| Bit Depth | 8, 10, 12 bitsImaging Teledyne e2v | |
| Sensor Modes | Multi-lines: 1S, 2S, 4S (16K pixels)Imaging Teledyne e2v | |
| Responsivity | 450 LSB 12bits/(nJ/cm²)Imaging Teledyne e2v | |
| Response Nonlinearity | < 1 % (5–95% saturation)Imaging Teledyne e2v | |
| Full Well Capacity | 27,300 electronsImaging Teledyne e2v | |
| Dynamic Range | 68.7 dB (4S mode)Imaging Teledyne e2v | |
| PRNU HF Max | 3 %Imaging Teledyne e2v | |
| Interface & Data Parameters | Data Interface | CameraLink® (4, 8, or 10 Taps at 85 MHz)Imaging Teledyne e2v |
| Max Data Rate | Up to 850 MB/sImaging Teledyne e2v | |
| Output Format | Mono8, Mono10, Mono12 | |
| Electrical Parameters | Power Supply | Single 12–24 VDCImaging Teledyne e2v |
| Power Dissipation | < 16 W (CameraLink mode)Imaging Teledyne e2v | |
| Inrush Current | Peak 1.8 A (12V)Imaging Teledyne e2v | |
| Operating Current | 1.06 A @12V; 0.54 A @24V (normal)Imaging Teledyne e2v | |
| Standby Current | 0.47 A @12V; 0.25 A @24VImaging Teledyne e2v | |
| Mechanical Parameters | Dimensions (W×H×L) | 125 × 60 × 35 mmImaging Teledyne e2v |
| Weight | 360 gImaging Teledyne e2v | |
| Lens Mount | F-Mount, T2, M42x1Imaging Teledyne e2v | |
| Sensor Alignment | ±100 µmImaging Teledyne e2v | |
| Sensor Flatness | ±50 µmImaging Teledyne e2v | |
| Environmental Parameters | Operating Temperature | 0–55 °C (front face); 0–70 °C (internal)Imaging Teledyne e2v |
| Storage Temperature | -40–70 °CImaging Teledyne e2v | |
| Humidity | 0–95% RH (non-condensing)Imaging Teledyne e2v | |
| Control & Features | Trigger Modes | Timed (Free run), External Trigger (Ext Trig), Ext ITCImaging Teledyne e2v |
| Analog Gain | Up to 12 dB (×4)Imaging Teledyne e2v | |
| Offset | -4096 to +4095 LSB (12-bit format)Imaging Teledyne e2v | |
| Built-in Functions | Flat Field Correction, Look Up Table, Anti-blooming, No LagImaging Teledyne e2v | |
| Regulatory Compliance | Certifications | CE, FCC Class A, RoHS compliantImaging Teledyne e2v |
