1 PCS used Panasonic MQDB012AAD02 AC Servo Drive #LYQ007
1 PCS used Panasonic MQDB012AAD02 AC Servo Drive #LYQ007
1 PCS used Panasonic MQDB012AAD02 AC Servo Drive #LYQ007
Part Number: MQDB012AAD02; Model: MQDB012AAD02; Product Name: Panasonic MQDB Series AC Servo Drive
Brand: Panasonic (Panasonic Industrial Devices, a trusted provider of high-precision servo systems for industrial automation, machinery, robotics and electronic manufacturing equipment)
Product Status: Standard Industrial-Grade Product (In Stock); Product Category: Digital AC Servo Drive, designed for low-power high-accuracy motion control applications with strict positioning demands
Core Application: Specialized for 0.1kW (100W) AC servo motor control in scenarios requiring precise positioning, stable operation and fast response, such as small industrial robots, precision assembly equipment, electronic component processing machines, textile machinery, automated testing devices and office automation equipment. Ideal for applications demanding low noise, high repeatability and compact installation space.
Core Features: Multi-mode control (Position/Speed/Torque) switchable; High-precision positioning via pulse command; Compact panel-mount design for space-saving; Rich optically isolated I/O interfaces for system integration; Built-in comprehensive protection functions; Low EMI emission adapting to harsh industrial environments; Easy configuration and tuning via dedicated software; Support for motor holding brake control.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance Parameters
Input Voltage: 1-Phase 200-230V AC (-15% to +10% fluctuation range), 50/60Hz; Rated Input Current: 1.2A (continuous), 3.6A (peak, 1 second duration);
Output Voltage: 3-Phase AC (PWM modulation, proportional to input voltage, frequency up to 20kHz); Output Current: 1.2A (continuous), 3.6A (peak, 1 second); Rated Output Power: 0.1kW (100W);
Control Modes: Position control (Pulse/Direction, CW/CCW, A/B Phase), Speed control (analog input, internal speed setting), Torque control (analog input) – switchable via parameter;
Positioning Accuracy: ±30 arc-seconds (matching 2500-line incremental encoder); Speed Range: 0-3000 rpm (continuous operation), 0-5000 rpm (intermittent operation); Speed Stability: ±0.01% of set speed (with encoder feedback, steady load);
Torque Response Time: ≤1ms (step torque command); Acceleration/Deceleration Time: 0.01s-300s (configurable, S-curve optional); Torque Control Precision: ±2% of rated torque.
2.2 Feedback & Communication Parameters
Feedback Interfaces: Differential incremental encoder input (5V DC), compatible with 2500-line encoders (standard for matching MQMA series servo motors); Supports position feedback for closed-loop control to ensure motion precision;
Communication Protocols: RS-485 (Modbus RTU), supporting remote parameter configuration, monitoring and fault diagnosis; Communication Speed: 9600/19200 bps (configurable via DIP switch or software);
I/O Interface: Digital Inputs x 6 (24V DC, sink type, optically isolated, response time ≤1ms); Digital Outputs x 3 (24V DC, max 0.5A per channel, optically isolated, open-collector type);
Analog Inputs x 2 (0-5V DC / 4-20mA, 12-bit resolution, configurable for speed/torque command); Analog Outputs x 1 (0-5V DC, 12-bit resolution, selectable output of speed, current or torque signals);
Safety Interface: Built-in overload protection (150% of rated current, 1 minute) and emergency stop signal input (24V DC), cooperating with external safety circuits to ensure operational safety.
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
