1 PCS used Yaskawa Servo Driver Mainboard SGDV-1R9DE1AY105AA#LYQ007
1 PCS used Yaskawa Servo Driver Mainboard SGDV-1R9DE1AY105AA#LYQ007
|
Item
|
Specification
|
|
Model Number
|
SGDV-1R9DE1AY105AA
|
|
Product Name
|
Yaskawa Servo Driver Mainboard, Industrial-Grade Precision Control Board for Servo Drive Systems
|
|
Brand & Manufacturer
|
Yaskawa Electric Corporation
|
|
Product Series
|
Yaskawa SGDV Series, Servo Driver Main Control Board, Compatible with SGDV-1R9DE Series Servo Drives
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
DSP Processing Speed
|
-
|
150
|
-
|
MHz
|
32-bit High-Performance DSP, Optimized for Servo Motion Control Algorithms
|
|
Control Cycle
|
0.1
|
1
|
10
|
ms
|
Software-configurable, Real-time Servo Control Cycle, Ensures High-precision Position/Speed/Torque Control
|
|
Position Control Accuracy
|
-
|
±0.01
|
±0.05
|
mm
|
Based on 1m Travel Distance, Matching Yaskawa Sigma-7 Series Servo Motors with Absolute Encoder
|
|
Speed Control Range
|
1
|
-
|
5000
|
r/min
|
Dependent on Compatible Servo Motor Specifications, Steady Speed Error ≤0.01%
|
|
Torque Control Range
|
0.1
|
-
|
100
|
%
|
Rated Torque of Compatible Servo Motor, Torque Control Accuracy ≤±1%
|
|
Encoder Feedback Support
|
-
|
-
|
-
|
-
|
Absolute Encoder (17-bit/23-bit), Incremental Encoder (Up to 2500 Lines); Support for Resolver Feedback (Optional)
|
|
Signal Processing Delay
|
-
|
5
|
10
|
μs
|
From Feedback Signal Input to Control Signal Output, Ensures Real-time Control
|
|
Parameter
|
Specification
|
|
Supply Voltage (Control Circuit)
|
DC 24V ±10%, 0.5A Maximum Current; Reverse Polarity Protection, Overvoltage Protection (≥30V DC)
|
|
Power Consumption (Control Circuit)
|
Typical 10W, Maximum 15W (Without Load, Ta=25℃)
|
|
Digital Input Channels
|
8 Channels, DC 24V, Sinking/Sourcing (Configurable); Response Time ≤10μs; Input Current 4.5mA (24V DC)
|
|
Digital Output Channels
|
8 Channels, DC 24V, Sinking; Maximum Current 0.5A per Channel, 4A Total; Short-Circuit Protection
|
|
Analog Input Channels
|
2 Channels, 4~20mA DC / 0~10V DC (Configurable); 16-bit Resolution; Input Impedance ≥10kΩ
|
|
Analog Output Channels
|
2 Channels, 4~20mA DC / 0~10V DC (Configurable); 16-bit Resolution; Output Impedance ≤100Ω; Short-Circuit Protection
|
|
Encoder Interface
|
1 x Absolute Encoder Interface (RS-485), 1 x Incremental Encoder Interface (Differential Signal); Support for 1Vpp Sin/Cos Encoder (Optional)
|
|
Communication Interfaces
|
1 x RS-485 (Terminal Block), Baud Rate 300bps~115200bps; 1 x Ethernet (RJ45), 10/100Mbps, Support Modbus TCP/IP; 1 x USB 2.0 (Type B) for Configuration
|
|
Isolation Voltage
|
2500Vrms (Control Circuit to Power Circuit, Channel to Channel), 1 Minute Duration per IEC 61131-2
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
