1PC for used Sumitomo MC-550 Drive PAU Power Supply UMC554000-03 #LYQ007
1PC for used Sumitomo MC-550 Drive PAU Power Supply UMC554000-03 #LYQ007
1PC for used Sumitomo MC-550 Drive PAU Power Supply UMC554000-03 #LYQ007
Part Number: UMC554000-03; Model: PAU Power Supply; Product Name: Sumitomo PAU Industrial Power Supply Module; Product Series: Sumitomo MC-550 Servo Drive Matching Power Supply Series, Dedicated Auxiliary Power Unit
Brand: Sumitomo (Sumitomo Heavy Industries, Ltd., a global leader in industrial machinery and automation components, specializing in servo drives, power modules, and precision motion control systems. The brand is renowned for reliable, high-performance industrial products tailored to machine tools, robotics, automotive manufacturing, and heavy-duty industrial applications worldwide.)
Product Status: Industrial-Grade Original Equipment (Factory Calibrated, 100% Functional, RoHS Compliant); Product Category: Dedicated PAU (Power Auxiliary Unit) for Servo Drives, engineered as the core power supply module for Sumitomo MC-550 servo drives, providing stable DC power for drive control circuits, logic operations, and auxiliary components.
Core Application: Exclusively matched with Sumitomo MC-550 servo drives in precision machine tools, robotic arms, automated assembly lines, material handling equipment, and heavy-duty industrial machinery. Specifically suitable for industrial scenarios requiring continuous, stable power supply with strong anti-interference capability and comprehensive protection functions to ensure reliable operation of servo drive systems.
Core Features: High-efficiency DC-DC conversion circuitry for stable power output; Dedicated design for seamless integration with Sumitomo MC-550 servo drives; Industrial-grade components ensuring durability in harsh industrial environments; Comprehensive protection functions against overvoltage, overcurrent, overheating, and short circuits; Low noise emission and strong electromagnetic compatibility; Compact modular design for space-saving installation; Built-in self-diagnostic functions for quick fault localization.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance Parameters
Input Power Supply: 3-Phase AC 200V~240V ±10% (50/60Hz), Voltage Frequency Range: 47Hz ~ 63Hz; Rated Input Current: 5A (Typical), Peak Input Current: 12A (10ms Duration);
Output Parameters: Main Output Voltage: DC 24V ±0.5V (Stable Output), Rated Output Current: 10A (Continuous), Peak Output Current: 20A (Short-Time, 3s); Auxiliary Output Voltage: DC 15V ±0.3V, Rated Output Current: 2A; Power Conversion Efficiency: ≥92% (Full Load), Low Ripple & Noise: ≤1% of Rated Output Voltage;
Voltage Regulation: ≤0.3% (Line Regulation), ≤0.5% (Load Regulation); Start-Up Time: ≤200ms (From Power-On to Stable Output); Hold-Up Time: ≥20ms (At Full Load, Input Voltage Interruption).
2.2 Control & Interface Parameters
Connection Interface: Dedicated Plug-in Connector (Compatible with Sumitomo MC-550 Servo Drive), Pin Configuration Matched with Drive Control Port; Signal Interface: 2×Status Signal Outputs (Optically Isolated, DC 24V), 1×Fault Alarm Output (Open Collector, Max 1A);
Control Functions: Built-in Voltage Monitoring, Current Monitoring, and Temperature Monitoring; Support for Drive-Side Power Status Feedback; Fault Reset: Manual Reset via External Signal or Drive System Command;
EMC Performance: Input EMC Filter Built-in (Compliant with EN 61000-6-4), Output Noise Suppression Circuit; ESD Protection: ±8kV (Contact), ±15kV (Air) Per IEC 61000-4-2; Surge Protection: ±2kV (Line to Line) Per IEC 61000-4-5.
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
