Item
|
Specification
|
|
Model Number
|
NJ501-5300 (CPU Unit, Firmware Version 1.21)
|
|
Product Name
|
OMRON Sysmac NJ Series CPU Unit, High-Performance Programmable Logic Controller
|
|
Brand & Manufacturer
|
OMRON Corporation
|
|
Product Series
|
Sysmac NJ Series, All-in-One Motion & Logic Controller, Firmware Version 1.21
|
2. Core CPU & Processing Specifications (Ta = 25℃, Unless Otherwise Specified)
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes (Firmware V1.21)
|
|
CPU Processing Speed (Logic)
|
-
|
0.08
|
-
|
μs/Step
|
Based on standard ladder logic (LD), Optimized in V1.21 for 5% faster processing than V1.20
|
|
CPU Processing Speed (Structured Text)
|
-
|
0.15
|
-
|
μs/Instruction
|
Basic ST instructions, Including arithmetic and logical operations
|
|
Motion Control Cycle
|
0.1
|
1
|
10
|
ms
|
Software-configurable, V1.21 supports 0.1ms cycle for high-precision multi-axis synchronization
|
|
Controllable Axes (Motion)
|
1
|
8
|
8
|
Axes
|
Support for linear/circular/ helical interpolation, Electronic cam, Electronic gear, V1.21 added support for 8-axis simultaneous interpolation
|
|
Program Memory Capacity
|
-
|
4
|
4
|
MB
|
Flash memory, Expandable via optional memory card, V1.21 supports up to 8MB optional memory
|
|
Data Memory Capacity
|
-
|
1
|
1
|
MB
|
SRAM, Retainable with backup battery, V1.21 optimized for data access speed
|
|
Task Processing Capacity
|
1
|
8
|
8
|
Tasks
|
Support for cyclic, event-triggered, and interrupt tasks, V1.21 added priority adjustment for motion tasks
|
|
Maximum I/O Points (Local + Remote)
|
-
|
8192
|
8192
|
Points
|
Combined digital + analog I/O, Via EtherCAT remote I/O modules (e.g., NX-ECC201), Supports up to 63 remote I/O units
|
3. Communication & Interface Specifications (Firmware V1.21)
|
Parameter
|
Specification
|
|
Built-in Ethernet Interfaces
|
2 x Gigabit Ethernet (RJ45): 1 x for Programming/Monitoring, 1 x for EtherCAT Master (Real-Time Communication); Auto-negotiation (10/100/1000 Mbps)
|
|
EtherCAT Communication (V1.21)
|
EtherCAT Master, Cycle Time: 0.1~100ms, Sync Signal Accuracy: ±1μs, Supports CoE (CANopen over EtherCAT), FoE (File over EtherCAT), EoE (Ethernet over EtherCAT); Compatible with NX-ECC series remote I/O couplers
|
|
Serial Interfaces
|
1 x RS-232C (DB9), 1 x RS-485 (Terminal Block); Baud Rate: 300 bps ~ 115200 bps; Support Modbus RTU (Master/Slave), ASCII Communication
|
|
USB Interface
|
1 x USB 2.0 (Type B), For Programming & Data Transfer; Compatible with Sysmac Studio Software (V1.21+); Data Transfer Rate: Up to 480 Mbps
|
|
Supported Industrial Protocols
|
EtherCAT, Modbus RTU, Modbus TCP (Optional), PROFINET (Optional), Ethernet/IP (Optional); V1.21 optimized Modbus TCP communication stability
|
|
Programming Interface
|
USB + Ethernet + RS-232C; Support Online Programming, Monitoring, and Debugging via Sysmac Studio; V1.21 added one-click firmware upgrade function
|
|
Remote I/O Communication
|
EtherCAT-based internal high-speed bus, Microsecond-level time accuracy for I/O synchronization; One NX-ECC series coupler can connect up to 10 I/O units, total 63 remote I/O units maximum
|
