1 PCS new Industrial Motherboard APCI5096 #LYQ007
1 PCS new Industrial Motherboard APCI5096 #LYQ007
1 PCS new Industrial Motherboard APCI5096 #LYQ007
Part Number: APCI5096; Model: APCI5096; Product Name: Industrial-Grade APCI Standard Motherboard
Brand: Industrial-Grade Component Manufacturer (Specializing in Industrial Motherboards, Embedded Systems, and Industrial Control Hardware for Harsh Environment Applications)
Product Status: Original Industrial-Grade Component (In Stock for Industrial Automation, Control System Integration, and Equipment Upgrade Projects); Product Category: APCI Form Factor Industrial Motherboard, Designed for High-Reliability and Long-Term Stable Operation in Industrial Scenarios.
Core Application: Specifically engineered for industrial control systems, factory automation equipment, data acquisition systems (DAQ), embedded industrial computers, and harsh-environment electronic devices. It serves as the core hardware platform for running industrial control software, processing real-time data, and coordinating peripheral devices, ensuring reliable operation in complex industrial environments with strong interference and variable temperatures.
Core Features: APCI Standard Form Factor for Easy Integration; Industrial-Grade Component Selection for Anti-Interference and Stability; Multiple Expansion Interfaces for Peripheral Compatibility; Built-In Fault Self-Diagnosis and Protection Functions; Wide Operating Temperature Range Adaptation; Passive Cooling Design for Silent Operation; Support for Long-Term Continuous Operation.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance Parameters
Operating Voltage: +12V DC ±10%, +5V DC ±5%, +3.3V DC ±5% (Dual Power Input for Stability); Power Consumption: ≤35W (Under Full Load Operating Conditions); No-Load Current: ≤1.2A (Total Current at 12V DC Input);
Processor Support: Compatible with Low-Power Industrial X86 Processors (Up to 2.0GHz, Dual-Core); Memory Support: 2x DDR4 SO-DIMM Slots, Maximum Capacity 32GB (2400MHz, ECC Optional for Error Correction); Storage Interface: 1x SATA III 6Gbps Port, 1x M.2 NVMe Slot (PCIe 3.0 x4), 1x CFast Card Slot;
Signal Processing: Integrated High-Speed I/O Controller, Support for Real-Time Data Transmission; Timing Accuracy: ±1μs (For Industrial Control Signal Synchronization); Expansion Bus: PCIe 3.0 x16, PCIe 3.0 x4, PCI 32-bit/33MHz Slots for Functional Expansion;
Isolation Performance: Opto-Isolation Voltage for Digital I/O Ports: ≥2500V AC (1 Minute); Isolation Resistance: ≥100MΩ (500V DC); EMI Filtering: Built-In Power and Signal EMI Filters to Meet Industrial Anti-Interference Requirements.
2.2 Interface & Communication Parameters
Communication Interfaces: 2x Gigabit Ethernet Ports (RJ45, Support for IEEE 802.3, Wake-on-LAN), 4x RS-232/RS-485 Serial Ports (Optically Isolated, Configurable via Software), 2x USB 3.0 Ports, 4x USB 2.0 Ports;
Protocol Support: TCP/IP, UDP, Modbus RTU/TCP, Profinet (Optional via Expansion Card), Ethernet/IP (Optional); Communication Speed: Gigabit Ethernet Up to 1000Mbps, RS-485 Up to 115200bps, USB 3.0 Up to 5Gbps;
Expansion Interface: 1x PCIe 3.0 x16 Slot, 1x PCIe 3.0 x4 Slot, 2x PCI 32-bit Slots, 1x GPIO Header (16 Channels, Configurable as Input/Output); Display Interface: 1x HDMI 2.0 Port, 1x VGA Port (Support for Dual Display);
Diagnostic Interface: Built-In LED Indicators (Power, System Run, Hard Disk Activity, Network Status), Support for BIOS-Level Fault Diagnosis, Real-Time Hardware Status Monitoring via Industrial Software.
3. Hardware Configuration & Mechanical Parameters
3.1 Hardware Configuration
Cooling System: Passive Convection Cooling (Reinforced Heat Dissipation Design with Aluminum Heat Sink on Key Components, Suitable for Fanless Industrial Cabinets); Indicator Lights: Power Indicator (Green), System Normal Indicator (Blue), Fault Alarm Indicator (Red), Network Activity Indicator (Yellow);
Protective Functions: Overvoltage Protection (15V DC for 12V Circuit), Overcurrent Protection (Per USB and Serial Port), ESD Protection (±15kV Contact, ±25kV Air), Short-Circuit Protection for Power Circuit, Over-Temperature Protection (Auto-Throttling at 70℃);
Core Components: Industrial-Grade CPU Chipset, High-Stability Memory Controller, EMI Filtering Modules, Anti-Surge Circuits, Gold-Plated Connectors for Enhanced Durability; Built-In Self-Test (BIST) Function for Hardware Integrity Check During Startup.
3.2 Mechanical & Installation Parameters
Dimensions (W × D × H): 312mm × 167mm × 40mm (12.28 inches × 6.57 inches × 1.57 inches, APCI Standard Form Factor, Excluding Connectors and Heat Sink); Mounting Type: Screw-Fixed Installation (Compatible with Standard Industrial Cabinet Rails and Chassis);
Weight: ≤1.2kg (Net Weight); Housing Material: FR-4 Reinforced Circuit Board with Anti-Corrosion, Anti-Dust, and Moisture-Proof Coating, Metal Shielding Cover for Key Circuits; Protection Grade: IP20 (Suitable for Indoor Industrial Control Cabinets);
Terminal Type: Gold-Plated Connectors (for Signal and Power, Anti-Oxidation and Wear Resistance), Locking USB and Serial Port Connectors (Anti-Loose Design); Fixing Method: Anti-Vibration Design to Resist Industrial Site Vibration and Shock.
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
