Item
|
Official Specification
|
|
Model Number
|
GM401.Z21
|
|
Product Name
|
Baumer GM401.Z21 Rotary Encoder
|
|
Brand & Manufacturer
|
Baumer Group, Switzerland (Original Factory)
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Supply Voltage (DC)
|
10
|
24
|
30
|
V
|
Stabilized power supply, ripple ≤ 100mVpp
|
|
Current Consumption
|
-
|
30
|
50
|
mA
|
At 24V DC supply voltage, no load
|
|
Output Interface
|
-
|
SSI
|
-
|
-
|
Synchronous Serial Interface, full-duplex, differential signal
|
|
Output Signal Type
|
-
|
RS422
|
-
|
-
|
Differential line driver, compatible with TIA/EIA-422-A
|
|
Data Transfer Rate
|
100
|
500
|
1000
|
kHz
|
Adjustable via external configuration, default 500kHz
|
|
Resolution (Single Turn)
|
-
|
13
|
-
|
Bits
|
8192 increments per full rotation, Gray code
|
|
Zero Reference Signal
|
-
|
1
|
-
|
Pulse/Rotation
|
Non-volatile, programmable zero position, active high
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Shaft Diameter
|
-
|
6
|
-
|
mm
|
Stainless steel shaft, polished surface, tolerance h7
|
|
Shaft Length
|
-
|
15
|
-
|
mm
|
Including shaft extension, excluding connector
|
|
Maximum Rotational Speed
|
-
|
6000
|
10000
|
rpm
|
Continuous operation, no mechanical damage
|
|
Starting Torque
|
-
|
0.015
|
0.03
|
N·m
|
At 25℃ ambient temperature, no load
|
|
Axial Load Capacity
|
-
|
5
|
10
|
N
|
Maximum axial force without affecting performance
|
|
Radial Load Capacity
|
-
|
8
|
15
|
N
|
Maximum radial force without affecting performance
|
|
Mounting Method
|
-
|
Flange Mount (FS)
|
-
|
-
|
Through-hole mounting, 4 M3 mounting holes, pitch circle diameter 30mm
|
|
Overall Dimensions (D×L)
|
-
|
40×58
|
-
|
mm
|
Diameter × Length, excluding cable and mounting bolts
|
|
Net Weight
|
-
|
0.12
|
-
|
kg
|
Without cable and accessories
|
