Part Number: ADV151-E63 S2; Model: ADV151-E63 S2; Product Name: Yokogawa ADV151 Series Analog Input DCS Card
Brand: Yokogawa (Yokogawa Electric Corporation, a global leader in industrial automation and control systems, providing high-reliability DCS modules for process industries)
Product Status: Standard Industrial-Grade Product (In Stock); Product Category: DCS Analog Input Card, designed for high-precision analog signal acquisition and processing in process control systems
Core Application: Widely used in oil & gas, petrochemical, chemical, power generation, water treatment and pharmaceutical industries. Suitable for connecting pressure, temperature, flow, level transmitters (such as Yokogawa EJA series) and other analog sensors, realizing stable signal acquisition and transmission to DCS control stations.
Core Features: High-precision analog signal conversion; Multi-channel signal acquisition; Excellent anti-electromagnetic interference performance; Built-in self-diagnostic function; Hot-swappable design (optional) for easy maintenance; Compatible with Yokogawa CENTUM VP DCS system; Wide operating temperature range for harsh industrial environments.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance Parameters
Operating Voltage: 24V DC ±10% (Power Supply from DCS Backplane); Power Consumption: ≤3W (Total for All Channels);
Input Channels: 8 Channels (Isolated Between Channels); Input Signal Type: 4-20mA DC (Two-Wire/Three-Wire Transmitter Compatible), 0-10V DC (Optional via Configuration);
Conversion Accuracy: ±0.05% FS (4-20mA DC), ±0.1% FS (0-10V DC); Resolution: 16-Bit; Sampling Rate: 10 Samples/Second Per Channel (Configurable Up to 100 Samples/Second);
Input Impedance: ≥100Ω (4-20mA DC), ≥1MΩ (0-10V DC); Signal Filtering: Configurable Digital Filter (Time Constant 0.1s-10s);
Insulation Resistance: ≥100MΩ @ 500V DC (Channel-Power, Channel-Channel); Dielectric Strength: 1500V AC, 1min (No Breakdown, No Arcing Between Channels and Power).
2.2 Communication & Interface Parameters
Backplane Interface: Compatible with Yokogawa CENTUM VP DCS Backplane; Communication Protocol: Yokogawa Proprietary High-Speed Bus (For Data Transmission with Control Station);
Diagnostic Interface: Supports Online Self-Diagnosis, Fault Signal Transmission to DCS System; Configuration Interface: Configurable via Yokogawa CENTUM VP Engineering Tool (CS 3000/VP);
Connector Type: Industrial-Grade Spring-Clamp Terminals (Anti-Vibration, Secure Connection); Terminal Pitch: 3.81mm (Standard Industrial Pitch).
2.3 Protection & EMC Parameters
Protection Functions: Over-Current Protection (Per Channel), Over-Voltage Protection (±30V DC Max Input), Short-Circuit Protection (Input to Ground);
ESD Protection: ±8kV (Contact), ±15kV (Air) Per IEC 61000-4-2; Surge Protection: ±2kV (Power Port), ±1kV (Signal Port) Per IEC 61000-4-5;
EMC Compliance: EN 55011 Class A (Electromagnetic Emission), EN 61000-4 Series (Electromagnetic Immunity); Insulation Class: F Grade.
