1 PCS used AMAT 0190-64677 MOXA NPort 6450-AMAT Serial Device Server #LYQ007
1 PCS used AMAT 0190-64677 MOXA NPort 6450-AMAT Serial Device Server #LYQ007
| Model | NPort 6450-AMAT |
| AMAT Part Number | 0190-64677 |
| Manufacturer | MOXA |
| Port Configuration | 4-port RS-232/422/485 to Ethernet secure serial port server |
| Ethernet Interface | 1 × 10/100BaseT(X) RJ45, auto MDI/MDI-X, 1.5 kV magnetic isolation |
| Serial Interface | 4 × DB9 male; RS-232/422/485; ADDC® (Automatic Data Direction Control) |
| Serial Protection | 15 kV ESD protection for all signals |
| Baud Rate | 50 bps to 921.6 kbps (supports non-standard baudrates) |
| Data Parameters | Data bits: 5, 6, 7, 8; Stop bits: 1, 1.5, 2; Parity: None, Even, Odd, Space, Mark |
| Flow Control | RTS/CTS, DTR/DSR, XON/XOFF |
| Operation Modes | Real COM, TCP Server, TCP Client, Pair Connection, Terminal, Reverse Terminal, UDP, RFC2217 |
| Security Protocols | SSL, SSH, DES, 3DES, AES encryption |
| Power Input | 12 to 48 VDC |
| Power Consumption | 730 mA @ 12 VDC; 330 mA @ 24 VDC |
| Alarm Contact | Relay output: 1 A @ 24 VDC (resistive load) |
| Port Buffer | 64 KB (internal); Up to 32 GB via SD card (SD 2.0 compatible) |
| Dimensions (with ears) | 181 × 103 × 35 mm (7.13 × 4.06 × 1.38 in) |
| Dimensions (without ears) | 158 × 103 × 35 mm (6.22 × 4.06 × 1.38 in) |
| Weight | 1020 g (2.25 lb) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 75 °C (-40 to 167 °F) |
| Humidity | 5 to 95% (non-condensing) |
| EMC Standards | IEC 61000-4-2 (ESD), IEC 61000-4-3 (RS), IEC 61000-4-5 (Surge), IEC 61000-4-6 (CS) |
| Certifications | CE, FCC |
| Housing | Metal |
| Mounting | DIN-rail, Rack-mount, Wall-mount |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
