1pc new Siemens Control Board AFO5100 6FL7820-8CC10-11#LYQ007
1pc new Siemens Control Board AFO5100 6FL7820-8CC10-11#LYQ007
|
Item
|
Specification
|
|
Model Number
|
6FL7820-8CC10-11
|
|
Product Name
|
Siemens AFO5100 Industrial Control Board
|
|
Product Series
|
Siemens AFO5100 Series, High-Precision Motion Control Board for Automation Systems
|
|
Brand
|
Siemens AG
|
|
Product Status
|
Industrial-Grade Original Equipment, RoHS 2.0 Compliant, CE Certified, UL Listed
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
Number of Control Axes
|
1
|
1
|
1
|
Axis
|
Single-axis independent motion control, support for position/speed/torque modes
|
|
Supply Voltage (DC)
|
18
|
24
|
30
|
V DC
|
Stabilized power supply required, ripple ≤ 1%
|
|
Rated Current Consumption
|
-
|
0.8
|
1.2
|
A
|
No-load/Full load condition
|
|
Communication Baud Rate
|
9600
|
19200
|
115200
|
Baud
|
USS protocol default 19200 baud, software configurable
|
|
Encoder Input Resolution
|
1024
|
4096
|
16384
|
PPR
|
Supports incremental encoder (TTL/HTL), 5V differential input
|
|
Control Precision
|
±0.001 mm (Mechanical), ±1 Pulse (Electrical)
|
Depends on encoder resolution and mechanical transmission
|
|||
|
Operating Frequency Range
|
0
|
50/60
|
400
|
Hz
|
Adjustable via configuration software
|
|
Parameter
|
Specification
|
|
Communication Interfaces
|
1 x USS Serial Interface (RS-485), 1 x Ethernet (RJ45, PROFINET Compatible), 1 x USB 2.0 (Configuration Port)
|
|
Encoder Interfaces
|
1 x Incremental Encoder Input (TTL/HTL, 5V DC), 1 x Absolute Encoder Input (SSI, Optional)
|
|
Digital Input/Output
|
6 Digital Inputs (Optically Isolated, 24V DC), 4 Digital Outputs (Transistor, 24V DC/0.5A), Configurable Functionality
|
|
Analog Input/Output
|
2 Analog Inputs (0~10V/4~20mA, 16-bit Resolution), 1 Analog Output (0~10V, 16-bit Resolution)
|
|
Power Connector
|
5-Pin Terminal Block (Power Input), 2.5mm² Wire Gauge Compatible
|
|
Signal Connectors
|
D-Sub 9 (Serial/Encoder), RJ45 (Ethernet), USB Type B (Configuration)
|
