1 PCS used AMAT 0100‑A0501 control board 30712570100 #LYQ007
1 PCS used AMAT 0100‑A0501 control board 30712570100 #LYQ007
| Parameter | Specification | Unit | Notes |
|---|---|---|---|
| Manufacturer | Applied Materials (AMAT) | - | Original Equipment Manufacturer |
| Main Board P/N | 0100‑A0501 | - | Primary Assembly Part Number |
| Assy P/N | 30712570100 | - | Full Assembly Identification |
| Product Type | OPAL CVC2 Board | - | Chamber Vacuum Control Board |
| Application | Semiconductor Process Equipment | - | For PVD/CVD/Etch Systems |
| Form Factor | Proprietary Backplane Board | - | AMAT OPAL Chassis Integration |
| Mounting | Chassis‑Specific Mount | - | Precision Alignment Required |
| Power Input | 24 VDC Nominal | VDC | Industrial Grade Low Voltage |
| Power Consumption | Typical 8–12 W | W | Operating Load Dependent |
| Operating Temp | 0 to +50 | °C | Standard Fab Environment |
| Storage Temp | -20 to +70 | °C | Non‑Operating |
| Humidity | 5–95% RH | % | Non‑Condensing |
| Interface | Backplane & Field I/O | - | Chamber Control & Sensor I/F |
| Board Material | FR‑4 | - | High‑Frequency Glass/Epoxy |
| Surface Finish | ENIG (Electroless Nickel/Immersion Gold) | - | Corrosion & Wear Resistant |
| Lead Finish | RoHS Compliant | - | Halogen Options Available |
| Weight (Typical) | 0.45 | kg | Shipping Weight Inc. Packaging |
| Revision Level | Factory Calibrated | - | Field Replaceable Unit (FRU) |
