1 PCS used D3E01507 GPDNET_MB2 board MT1505-0071MR #LYQ007
1 PCS used D3E01507 GPDNET_MB2 board MT1505-0071MR #LYQ007
| Parameter Group | Parameter ID | Parameter Name (English) | Default Value | Min Value | Max Value | Unit | Description |
|---|---|---|---|---|---|---|---|
| Communication Basic | COM-001 | Node Address | 1 | 1 | 247 | - | Modbus node address for network communication |
| Communication Basic | COM-002 | Baud Rate | 9600 | 2400 | 115200 | bps | Serial communication baud rate selection |
| Communication Basic | COM-003 | Parity Check | None (0) | 0 (None) | 2 (Odd) | - | 0=None, 1=Even, 2=Odd; sets parity type |
| Communication Basic | COM-004 | Data Bits | 8 | 7 | 8 | - | Number of data bits per frame |
| Communication Basic | COM-005 | Stop Bits | 1 | 1 | 2 | - | Number of stop bits per frame |
| Communication Basic | COM-006 | Communication Timeout | 500 | 100 | 2000 | ms | Timeout for communication response |
| Network Interface | NET-001 | IP Address | 192.168.1.100 | - | - | - | Static IP address for Ethernet interface |
| Network Interface | NET-002 | Subnet Mask | 255.255.255.0 | - | - | - | Subnet mask for network configuration |
| Network Interface | NET-003 | Gateway | 192.168.1.1 | - | - | - | Default gateway IP address |
| Network Interface | NET-004 | DHCP Mode | Disable (0) | 0 (Disable) | 1 (Enable) | - | 0=Static IP, 1=DHCP auto-acquisition |
| Data Transmission | DAT-001 | Data Update Cycle | 100 | 10 | 1000 | ms | Cycle for real-time data refresh |
| Data Transmission | DAT-002 | Transmit Error Retries | 3 | 1 | 10 | - | Number of retries for failed transmission |
| Fault Protection | Flt-001 | Communication Fault Response | Stop (1) | 0 (None) | 1 (Stop) | - | 0=None, 1=Stop drive on communication loss |
| Hardware | HW-001 | Firmware Version | - | - | - | - | Current firmware release of the board |
| Hardware | HW-002 | Board Status | Normal | Fault | - | - | Real-time status of the communication board |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
