1 PCS new Siemens 1FK7042-2AF71-1CG1 AC Servo Motor #LYQ007
1 PCS new Siemens 1FK7042-2AF71-1CG1 AC Servo Motor #LYQ007
| Parameter | Value |
|---|---|
| Model | 1FK7042-2AF71-1CG1 |
| Motor Type | SIMOTICS S-1FK7 Synchronous Servo Motor (1FK7-CT) |
| Rated Power (PN) | 0.82 kW |
| DC Link Voltage (UDC) | 600 V |
| Rated Torque (M0, 100K) | 3 Nm |
| Rated Speed (NN) | 3000 rpm |
| Cooling | Naturally cooled |
| Mounting | IMB 5 (IM V1, IM V3), Flange 1 |
| Power Connector | Rotatable |
| Encoder | Absolute encoder, 24‑bit single‑turn + 12‑bit multi‑turn, DRIVE‑CLiQ interface (AM24DQI) |
| Shaft | Smooth shaft, tolerance N |
| Holding Brake | Without holding brake |
| Protection Class | IP65 |
| Frame Size | 48 |
| Number of Poles | 8‑pole |
| Rated Current | 2.0 A |
| Stall Current (100K) | 2.2 A |
| Torque Constant (KT) | 1.38 Nm/A |
| Max. Permissible Speed | 6400 rpm (inverter) / 9000 rpm (mechanical) |
| Max. Torque | 10.5 Nm |
| Max. Current | 7.6 A |
| Moment of Inertia | 3.81 kg·cm² |
| Insulation Class | Class F |
| Ambient Temperature | −15 °C to +40 °C |
| Shaft Dimensions | Ø 19 mm × 40 mm length |
| Typical Applications | Machine tools, robots, handling systems, packaging, plastics, textile machines |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
