1 PCS KEYENCE BT-W350G Handheld Barcode Reader#LYQ007
1 PCS KEYENCE BT-W350G Handheld Barcode Reader#LYQ007
| Item | Specifications |
|---|---|
| Model | BT-W350G |
| Type | Camera type |
| Controller | |
| CPU | ARM Cortex® Triple Core |
| OS | Microsoft® Windows® Embedded Compact 7 |
| Memory | |
| RAM | 512 MB (Disk: 32 MB) |
| ROM | 512 MB (Disk: 222 MB), Flash-ROM |
| Display | |
| LCD | 3.5-inch transmissive TFT color LCD, VA type |
| Resolution | 480 (W) × 640 (H) dots (VGA) |
| Colors | 65,536 colors |
| Backlight | High-brightness white LED |
| Status LED | 3-color LED (Red, Green, Blue, Yellow, Cyan, Magenta, White) |
| Operation | |
| Touch Panel | Analog resistive film (tempered glass) |
| Hard Keys | 1 × 4-way cursor, 3 × trigger (1 center, 2 side), 8 × function (F1–F4, Fn, Tab, Character, Shift), 14 × data input (numeric, ENT, Clear, Minus, Symbol), 1 × power |
| Scanner | |
| Illumination | High-brightness white LED |
| Pointer | Visible semiconductor laser (657 nm), 1.0 mW output, Class 2 (IEC60825-1) |
| Min. Resolution | 2D: 0.127 mm; 1D: 0.076 mm |
| Reading Distance | 30–840 mm (CODE39, 0.508 mm); 25–450 mm (CODE39, 0.254 mm); 30–480 mm (QR, 0.508 mm); 25–280 mm (QR, 0.254 mm) |
| Field of View | 124 × 76 mm (at 180 mm reading distance) |
| Supported Codes | JAN/EAN/UPC (add-on), CODE128, GS1-128, CODE39, NW-7 (Codabar), CODE93, ITF, COOP 2of5, Industrial 2of5, QR, Micro QR, DataMatrix (ECC200), PDF417, GS1 DataBar, Composite |
| Wireless | |
| WLAN | IEEE802.11 a/b/g/n; 2.4 GHz (1–13 ch), 5.2/5.3 GHz (a/n) |
| Security | WEP (64/128-bit), WPA/WPA2; TKIP/AES; PSK/EAP-TLS/PEAP-MSCHAP-V2 |
| Bluetooth | V2.1 + EDR; SPP, PAN (PANU), FTP (Client), HSP (AG), HID (Host/Device); ~10 m (line-of-sight) |
| External Storage | |
| Media | microSD / microSDHC (max 32 GB) |
| Power | |
| Main Battery | Li-ion battery pack, 3250 mAh |
| Continuous Operation | Mode 1: ~19 h; Mode 2: ~22 h; Mode 3: ~19 h |
| Charging Time | ~8 h (room temp) |
| Backup | Clock: built-in Li-ion (~1 month); RAM: electric double-layer capacitor (~1 min) |
| Environmental | |
| Protection | IP64 |
| Operating Temp | −20 to +50 °C (no freezing) |
| Humidity | 20–85% RH (no condensation) |
| Storage Temp | −20 to +60 °C (no freezing) |
| Drop Resistance | 2.0 m onto concrete (3.5 m with protector); 20,000 tumbles from 30 cm |
| Physical | |
| Dimensions | 193 × 75.2 × 38.5 (30.3) mm (grip in parentheses) |
| Weight | ~256 g (with battery) |
| Other | |
| Buzzer | 16 tones, 3 volume levels |
| Vibration | Yes |
| Calendar/Clock | Auto-calendar (to 2079), ±80 sec/month (room temp) |
| EMI | VCCI Class A |
| Accessory | Hand strap |
