1 PCS used HOKUYO DMJ-GB1-Z50 SENSOR #LYQ007
1 PCS used HOKUYO DMJ-GB1-Z50 SENSOR #LYQ007
| Parameter | Details |
|---|---|
| Model | DMJ-GB1-Z50 (Sensor Head) |
| Type | Modular Type Optical Data Transmission Device (SEMI E84 Standard) |
| Communication Direction | Head-ON |
| Transmission Distance | 1.0 m (Adjustable) |
| Directional Angle | 30° (Full angle) |
| Transmission Capacity (I/O) | 8 bits Input / 8 bits Output |
| Transmission System | Half-duplex two-way |
| Transmission Time | 45 msec |
| Power Supply | 24 VDC (±10%) |
| Current Consumption | 100 mA Max. |
| Ambient Illuminance | 4,000 lx or less |
| Ambient Temperature | -10°C to +50°C |
| Ambient Humidity | 85% RH or less (Non-condensing) |
| Vibration Resistance | Double amplitude 1.5 mm, 10 to 55 Hz, 2 hours each in X, Y, Z directions |
| Impact Resistance | 500 m/s², 10 times each in X, Y, Z directions |
| Protective Structure | IP40 |
| Connection (Connector) | D-sub 25-pin connector |
| Modulating System | Pulse modulation |
| Detection System | Parity check (Outputs turn OFF at 2 consecutive errors) |
| Communication (Head-Connector) | RS-485, 38.4 kbps |
| Head-Connector Cable | RJ-11 (6P4C), Max. 200 m (AWG26) |
| Logging Function | Data change log: Max. 1600 times |
| Memory | Ferroelectric (8 KB), 10-year data retention |
| Output Type | NPN open-collector (30 VDC, 50 mA, Residual voltage ≤ 1.8 V) |
| Input | IN1-IN8, SELECT, MODE; ON current ≥ 2.5 mA, OFF current ≤ 1 mA |
