1 PCS new NSK M-EDC-PN4135AB5F7 Driver Unit #LYQ007
1 PCS new NSK M-EDC-PN4135AB5F7 Driver Unit #LYQ007
| Item | Specifications |
|---|---|
| Model | M-EDC-PN4135AB5F7 |
| Rated Output Current [Arms] | 4.5 |
| Maximum Output Current [Arms] | 14.9 |
| Rated Capacity [kVA] | 0.9 |
| Maximum Capacity [kVA] | 5.0 |
| Main Power Source | Single-phase 200–230 VAC, ±10% |
| Control Power Source | Single-phase 200–230 VAC, ±10% |
| Position Sensor Resolution [count/rev] | 2,621,440 (Max. 1,310,720 count/rev; Quadrupled: 5,242,880 count/rev) |
| Positioning Operation Mode | Program operation (256 channels), Pulse train input, RS-232C, Jog, Home Return |
| Pulse Train Command | Photo coupler input; Max. pulse frequency: 1 MHz; Input formats: CW/CCW, Pulse+Direction, ΦA/ΦB |
| Control Input | 17 ports, 24 VDC photo coupler input |
| Position Feedback Signal | ΦA/ΦB/ΦZ line drive; ΦA/ΦB resolution: 20,480 count/rev (81,920 quadrupled); ΦZ: 80 count/rev |
| Control Output | 7 ports, 24 VDC/50 mA photo coupler output |
| Communication | RS-232C (9,600 bps); CC-Link Ver.1.10 compatible (optional) |
| Data Backup | EEPROM (100,000 write/erase cycles) |
| Ambient Temperature | 0–50 °C |
| Storage Temperature | −20–70 °C |
| Humidity | ≤90% RH (non-condensing) |
| Vibration Resistance | 4.9 m/s² |
| Regeneration | Built-in resistor; external dump resistor optional |
| Dynamic Brake | Available |
| Safety Standards | UL508C, EN50178, LVD, EN55011 (EMI), EN61000-6-2 (EMS) |
| Mass [kg] | Standard: 1.8; CC-Link compatible: 2.0 |
| Connectors | CN1: D-sub 9 pins; CN2: 50-pin half-pitch; CN3: 14-pin half-pitch; CN4/CN5: Plastic; CN6: 5-pin plastic |
