1 PCS used GSI GROUP (GSI Lumonics) E19014580 Optical Rotary Encoder #LYQ007
1. General Information
Manufacturer: GSI Group (GSI Lumonics, MicroE Systems)
Part Number: E19014580
Alternate Name: 88-Y233 (Varian)
Type: Incremental Optical Rotary Encoder
Application: Precision position feedback for Varian ion implanter stages
Parameter
Value
Supply Voltage (VDD)
5 VDC ±5%
Current Consumption
<100 mA (typical)
Output Signal Type
Differential Line Driver (RS-422)
Channels
A, /A, B, /B, Z, /Z (Quadrature)
Resolution (CPR)
1000 Counts Per Revolution
Line Count (PPR)
250 Pulses Per Revolution
Phase Shift
A/B: 90° ±45° (Quadrature)
Index Pulse (Z)
1 pulse per revolution
Max Output Frequency
1 MHz
Rise/Fall Time
<100 ns
Output Logic
TTL Compatible
Parameter
Value
Shaft Type
Solid, Diameter 6 mm (0.236 in)
Body Diameter
37 mm (1.46 in)
Body Length
28 mm (1.10 in)
Max Shaft Speed
12,000 RPM
Bearing Life
100,000 hours MTBF
Shaft Loading
Axial: 40 lbs max; Radial: 35 lbs max
Rotational Torque
<1.5 in-oz (typical)
Mounting
4-bolt flange, 25 mm bolt circle
Connector
10-pin MS3102E18-1P circular connector
