1 PCS Panasonic HG-S1110-AC Contact-Type Digital Displacement Sensor#LYQ007
1 PCS Panasonic HG-S1110-AC Contact-Type Digital Displacement Sensor#LYQ007
| Item | Specifications |
|---|---|
| Model | HG-S1110-ACPanasonic |
| Type | Air-driven type, High precision, 10 mm typePanasonic |
| Position detection method | Optical absolute linear encoder methodPanasonic |
| Measurement range | 10 mm (0.394 in)Panasonic |
| Stroke | 10.5 mm (0.413 in) or morePanasonic |
| Resolution | 0.1 μm (0.004 mil)Panasonic |
| Sampling cycle | 1 msPanasonic |
| Indication accuracy (P-P) | Full range: ≤ 1.0 μm (0.039 mil); Narrow range (any 60 μm): ≤ 0.5 μm (0.020 mil)Panasonic |
| Tip deviation amount | 35 μm (1.378 mil) (typical value)Panasonic |
| Hot-swap function | IncorporatedPanasonic |
| Working pressure range | 0.14 to 0.16 MPa; With no seal cap: 0.035 to 0.045 MPaPanasonic |
| Pressure resistance | 0.2 MPaPanasonic |
| Usable fluid | Clean air (Dew point temperature: ≤ -10 °C / +14 °F)Panasonic |
| Applicable tube | Outside diameter: ø4 mm (0.157 in); Inside diameter: ø2.5 mm (0.098 in)Panasonic |
| Operation indicator | 2-color LED (Orange / Green)Panasonic |
| Pollution degree | 2Panasonic |
| Operating altitude | ≤ 2,000 m (6561.68 ft)Panasonic |
| Protection | IP67 (IEC) (Seal cap mounted)Panasonic |
| Ambient temperature | Operation: -10 to +55 °C (+14 to +131 °F, no condensation/icing); Storage: -20 to +60 °C (-4 to +140 °F)Panasonic |
| Ambient humidity | Operation/Storage: 35 to 85 % RHPanasonic |
| Insulation resistance | ≥ 100 MΩ (250 V DC)Panasonic |
| Vibration resistance | 10 to 500 Hz, 3 mm double amplitude (10–58 Hz), max. 196 m/s² (58–500 Hz), X/Y/Z, 2 hours eachPanasonic |
| Shock resistance | 1,960 m/s² acceleration, X/Y/Z, 3 times eachPanasonic |
| Grounding | Capacitor groundingPanasonic |
| Material | Body: Zinc; Holder: Stainless steel; Spindle: Tool steel; Probe: Ceramic; Air tube clamp: S60CMPanasonic |
| Weight | Approx. 80 g (net)Panasonic |
| Compatible controller | HG-SC101(-P), HG-SC111(-P), HG-SC112(-P), HG-SC113 (manufactured Feb 2019 or later)Panasonic |
| Regulatory compliance | EMC Directive, RoHS DirectivePanasonic |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
