Category    English Specification    Remarks
Model Number    Q170ENC-W8    Mitsubishi MELSEC-Q Series Absolute Encoder Positioning Module
Product Type    Absolute Encoder Positioning Module    2-channel absolute encoder interface
Encoder Type    Absolute Encoder    Serial communication (2.5 Mbps)
Resolution    262144 PLS/res    High precision position detection
Max. Allowable Speed    3600 r/min    Encoder rotational speed limit
Axis Load Capacity    Radial: 19.6 N; Axial: 9.8 N    Mechanical load specifications
Input Power    10.2–26.4 V DC (ripple ≤ 5%)    Power supply range
Input Interface    2 channels    Common positive/negative terminal (opto-isolated)
Input Voltage/Current    12 V DC / 2 mA; 24 V DC / 4 mA    Signal input specifications
Response Time    0.4 ms, 0.6 ms, 1 ms (OFF→ON, ON→OFF)    CPU parameter configurable, default 0.4 ms
I/O Points Occupied    32 points    Intelligent function module allocation
External Dimensions    98.0 (H) × 27.4 (W) × 90.0 (D) mm    Module physical size
Weight    Approx. 0.15 kg    Net weight for logistics
Operating Temperature    0–55 °C (32–131 °F)    Ambient temperature range
Storage Temperature    -25–75 °C (-13–167 °F)    Non-operating temperature range
Humidity    5–95% RH (non-condensing)    Environmental humidity tolerance
Vibration Resistance    10–55 Hz, 0.075 mm double amplitude    Mechanical vibration durability
Shock Resistance    15 G (11 ms duration)    Mechanical shock tolerance
Battery    A6BAT/MR-BAT    Backup battery for absolute data

1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
