1 PCS USED HEIN LANZ Encoder 10-58HN-1024-SG82 #LYQ007
1 PCS USED HEIN LANZ Encoder 10-58HN-1024-SG82 #LYQ007
1 PCS USED HEIN LANZ Encoder 10-58HN-1024-SG82 #LYQ007
Original Factory Precision Parameters (Brand: HEIN LANZ; Product: Genuine Original Encoder; Model: 10-58HN-1024-SG82)
|
Parameter Category
|
Parameter Name
|
10-58HN-1024-SG82 Specification
|
|
Basic Information
|
Product Model
|
10-58HN-1024-SG82; Genuine Original HEIN LANZ Encoder, 100% brand-new, unused and unrefurbished genuine parts; High-precision industrial photoelectric encoder.
|
|
Manufacturer Standard
|
Complies with IEC 60908, EN 60908, DIN 40050 Standards; Conforms to HEIN LANZ internal technical and quality norms for industrial encoders; Passes strict factory precision calibration and performance testing.
|
|
|
Product Application
|
Industrial Automation Equipment, CNC Machine Tools, Mechanical Transmission Systems, Robotics, Printing Machinery, Packaging Equipment, Textile Machinery, Position and Speed Feedback Scenarios.
|
|
|
Product Type
|
Incremental Photoelectric Encoder; Solid-shaft Encoder; Industrial-grade, high-precision position and speed feedback component, supporting stable signal transmission in harsh industrial environments.
|
|
|
Core Electrical Parameters
|
Encoder Type
|
Incremental Photoelectric Encoder; 3-channel Output (A, B, Z); Differential Output (Line Driver); Anti-interference design for long-distance signal transmission.
|
|
Resolution (Pulse/Rotation)
|
1024 Pulses per Rotation (1024 PPR); Precision Grade: ±0.1°; No pulse loss under rated speed, ensuring high-precision position feedback.
|
|
|
Rated Working Voltage
|
DC 5V ±10% (Standard); Optional DC 12V/24V ±10%; Stable power supply ensures consistent signal output, low power consumption design.
|
|
|
Output Signal Type
|
Differential Line Driver Output (RS422); A, A-, B, B-, Z, Z- Channels; Compatibility with industrial PLC, motion controller and other receiving devices.
|
|
|
Maximum Response Frequency
|
≥ 100 kHz; Supports high-speed rotation feedback, no signal distortion when rotating at maximum rated speed.
|
|
|
Phase Difference
|
A/B Phase 90° ±10°; Clear phase difference for direction recognition, avoiding direction misjudgment in motion control scenarios.
|
|
|
Z-channel Characteristics
|
1 Pulse per Rotation; Z-channel Pulse Width: 1/4 ~ 1/2 of A/B Channel Pulse Width; Used for zero position calibration and origin positioning.
|
|
|
Insulation Resistance
|
≥ 100 MΩ (500V DC); Excellent insulation performance, preventing short circuit caused by insulation breakdown in industrial environments.
|
|
|
Withstand Voltage
|
1 kV AC (1 min); Can withstand instantaneous overvoltage impact, ensuring stable operation in complex electrical environments.
|
|
|
Mechanical Parameters
|
Shaft Diameter
|
10 mm (Solid Shaft); Shaft Material: High-precision Stainless Steel; Surface Polishing Treatment, wear-resistant and corrosion-resistant.
|
|
Maximum Rotational Speed
|
5000 RPM (Continuous Operation); 6000 RPM (Short-term Peak, ≤ 10 minutes); No mechanical wear or signal loss at maximum speed.
|
|
|
Shaft Load Capacity
|
Radial: ≤ 20 N; Axial: ≤ 10 N; Strong shaft load capacity, adapting to various mechanical installation scenarios without affecting precision.
|
|
|
Dimensions (D×L)
|
58 mm (Outer Diameter) × 45 mm (Length); Compact structural design, small installation space, suitable for narrow installation environments.
|
|
|
Weight
|
0.24 kg (Net Weight); Light weight, easy to install and fix; Does not increase the load of mechanical equipment.
|
|
|
Mounting Type
|
Flange Mounting (Clamping Synchronous Flange); Compatible with standard industrial mounting dimensions, easy to assemble and disassemble.
|
|
|
Environmental & Protection Parameters
|
Operating Temperature
|
-30℃ ~ +80℃ (Ambient Temperature); Stable operation in wide temperature range, suitable for harsh industrial high and low temperature environments.
|
|
Storage Temperature
|
-40℃ ~ +90℃; Stable storage performance, convenient for transportation and inventory; No performance degradation after long-term storage.
|
|
|
Relative Humidity
|
10% ~ 95% (Non-Condensing); Resists humid industrial environments, no short circuit or signal distortion caused by humidity.
|
|
|
Vibration Resistance
|
10 ~ 500 Hz, 20 g Amplitude; Resists strong mechanical vibration, no parameter drift or internal component damage.
|
|
|
Shock Resistance
|
980 m/s² (100 g), 11 ms; Resists mechanical impact during transportation and operation, ensuring product integrity and performance stability.
|
|
|
Protection Level
|
IP54; Dustproof and Waterproof, Protected against solid objects with diameter ≥ 1.0 mm and splashing water from all directions, suitable for harsh industrial sites.
|
|
|
Service Life
|
≥ 20000 Operating Hours (Continuous Operation, Standard Working Conditions); Long service life, reducing maintenance costs and equipment downtime.
|
|
|
Other Technical Parameters
|
Cable Length
|
1.0 m (Standard); Optional 2.0 m / 3.0 m; High-temperature resistant and oil-resistant cable, suitable for industrial environment wiring.
|
|
Compatibility
|
Perfectly Compatible with Various Industrial PLCs, Motion Controllers, Frequency Converters and Data Acquisition Devices; Matching with mainstream industrial control systems.
|
|
|
Factory Calibration
|
100% Factory Calibrated; Strict performance testing and precision calibration before leaving the factory, all parameters consistent with HEIN LANZ official specifications.
|
|
|
Rotation Direction
|
Clockwise (CW) or Counterclockwise (CCW) Optional; Default: Clockwise (A Channel Leading B Channel by 90°); Direction can be customized according to user requirements.
|
|
|
Maintenance Cycle
|
Recommended Maintenance Cycle: 3000 Operating Hours; Regular inspection of cable and mounting status extends the service life and ensures stable performance.
|
