1PC used working PN-152564 distributor internal SKU for the Allen‑Bradley 20‑750‑2262C‑2R Control Core Board (PowerFlex 753/755 drives) #QYM001 J1688
1PC used working PN-152564 distributor internal SKU for the Allen‑Bradley 20‑750‑2262C‑2R Control Core Board (PowerFlex 753/755 drives) #QYM001 J1688
| Category | Parameter | Details |
|---|---|---|
| Basic Identification | Product Name | PowerFlex 750 Control Core Board (20G/20H frames) |
| Catalog Number | 20‑750‑2262C‑2R | |
| Alternative ID | PN‑152564 (distributor internal code) | |
| Compatibility | PowerFlex 753/755 AC Drives (20G/20H frame sizes) | |
| Primary Function | Hosts CPU, control logic, I/O interface, communication protocol processing | |
| Electrical | Operating Voltage | 5 VDC (logic), 24 VDC (auxiliary I/O, drive‑supplied) |
| Current Consumption | 1.2 A max (5 VDC); 0.3 A max (24 VDC) | |
| Isolation Rating | 2500 V AC (control‑to‑power circuits) | |
| Communication | Interfaces | - Drive Peripheral Interface (DPI) for I/O expansion
|
| I/O | Digital I/O | 4 configurable inputs; 2 relay outputs (2 A @ 240 V AC) |
| Analog I/O | 1 input (0–10 V DC / 4–20 mA); 1 output (0–10 V DC / 4–20 mA) | |
| Mechanical | Mounting | Internal drive chassis (slide‑in connector, tool‑less) |
| Dimensions | 185 mm (L) × 110 mm (W) × 25 mm (H) | |
| Weight | 0.28 kg (≈0.62 lbs) | |
| Environmental | Operating Temperature | -10°C to +50°C (no derating); +50°C to +60°C (derated) |
| Storage Temperature | -40°C to +85°C | |
| Humidity | 5%–95% RH (non‑condensing, no corrosive gases) | |
| Vibration | 2 g RMS (5–500 Hz, IEC 60068‑2‑6) | |
| Certifications | Approvals | CE, UL, CUL, CCC, KC, UKCA; ATEX (optional) |
| Key Features | Functionalities | - Studio 5000/DriveExecutive compatible
|
