1 PCS new KITZ SCT IB8CS-VCC-STD-316L Bellows Valve #LYQ007
1 PCS new KITZ SCT IB8CS-VCC-STD-316L Bellows Valve #LYQ007
| Parameter | Specification |
|---|---|
| Model Number | IB8CS-VCC-STD-316LKITZ SCT CORPORATION |
| Type | Compact Pneumatic Bellows Valve (2-way, Straight)KITZ SCT CORPORATION |
| Body Material | SUS316L Stainless SteelKITZ SCT CORPORATION |
| Connection Type | Male CVC (VCC)KITZ SCT CORPORATION |
| Connection Size | 1/2 inchKITZ SCT CORPORATION |
| Flow Coefficient (Cv) | 0.85KITZ SCT CORPORATION |
| Max. Operating Pressure | 0.98 MPa (G) / 142 psig |
| Actuation | Normally Closed (NC)KITZ SCT CORPORATION |
| Operating Pressure | 0.4 ~ 0.7 MPa (G) / 58 ~ 102 psig |
| Fluid Temperature Range | -10°C to 100°CKITZ SCT CORPORATION |
| Ambient Temperature Range | -10°C to 60°CKITZ SCT CORPORATION |
| Seat Material | PCTFEKITZ SCT CORPORATION |
| Bonnet Gasket | PCTFEKITZ SCT CORPORATION |
| Surface Finish | STD (Mechanical Polish, Rz ≤ 3.2 μm) |
| Leak Rate | Internal: ≤ 1×10⁻¹⁰ Pa·m³/s (He) |
| Cycle Life | Approx. 30,000 cycles |
