1 PCS new Schneider ARROW LAX‑24‑A Explosion‑Proof Signal Light #LYQ007
1 PCS new Schneider ARROW LAX‑24‑A Explosion‑Proof Signal Light #LYQ007
| Parameter | Specification |
|---|---|
| Model | LAX‑24‑A (Schneider ARROW) |
| Type | LED Explosion‑Proof Signal Light |
| Rated Voltage | AC/DC 24 V |
| Operating Voltage Range | 21.6 – 26.4 V |
| Power Consumption | 3 W (steady‑on) / 2.5 W (flashing) |
| Light Source | High‑brightness LED |
| LED Life | Min. 54,000 hours |
| Shape | Bullet‑type |
| Outer Diameter | Φ 84 mm |
| Dimensions | Φ 84 × 86 mm (body) |
| Total Length | 136 mm |
| Weight | 210 g |
| Protection Rating | IP23 (direct‑mount) |
| IP65 (with optional rubber base) | |
| Vibration Resistance | 70 m/s² (7.1 G) |
| Connection | NPN/PNP open‑collector compatible |
| Flashing Control | External signal‑controlled (steady‑on / flashing / alternate flashing) |
| Material | Lens: impact‑resistant polycarbonate |
| Body: oil‑resistant alloy resin | |
| Explosion‑Proof Certification | ATEX, IECEx, cULus, ULC, TR CU, CQST, INMETRO, CCOE |
| Hazardous Area Classification | Zone 1, 2, 21, 22 |
| ATEX/IECEx Marking | Ex II 2GD, Ex db IIC T4/T5/T6 Gb; Ex tb IIIC T135°C/T100°C/T85°C Db |
| Operating Temperature | −55°C to +70°C |
| Standards | EN/IEC 60079‑0, EN/IEC 60079‑1, EN/IEC 60079‑7, EN/IEC 60079‑18, EN/IEC 60079‑31 |
