Part Number: cPCI-6842/PM16/M512/H40G(G); Product Name: Advantech cPCI-6842 CompactPCI Industrial Motherboard
Brand: Advantech (A global leader in industrial computing solutions, specializing in industrial motherboards, embedded systems, and automation control products for harsh industrial environments);
Product Status: Original New Unit; Product Category: 3U CompactPCI Industrial Motherboard, compliant with PICMG 2.0 R3.0 standard, integrated with high-performance processor, memory and expansion interfaces for industrial control and test applications.
Core Application: Widely used in industrial automation control systems, test and measurement equipment, military and aerospace systems, transportation control, power grid monitoring, and other harsh environment applications requiring high reliability and stable operation;
Core Features: Compliant with CompactPCI PICMG 2.0 specification; Integrated high-performance processor and memory module; Multiple expansion interfaces; Industrial-grade design for anti-interference and stability; Wide operating temperature range; Support for multiple operating systems.
2. Hardware Configuration Specifications
2.1 Processor & Memory Capability
Processor: Integrated high-performance industrial-grade processor (PM16); Processor Architecture: Compatible with x86 architecture; Operating Frequency: Optimized for industrial stability, supporting low-power and high-efficiency operation;
Memory Configuration: 512MB (M512) DDR2 SDRAM, support for dual-channel mode; Memory Frequency: DDR2 800/667MHz; Maximum Memory Expansion: Up to 4GB (depending on processor compatibility); Storage Interface: Support for SATA II interface, compatible with industrial hard drives and SSDs.
2.2 Bus & Expansion Configuration
Bus Standard: CompactPCI PICMG 2.0 R3.0, 32-bit/66MHz PCI Local Bus Rev.2.2; Data Transfer Rate: Up to 200MB/s (at 66MHz); Expansion Slots: Support for on-board expansion interfaces and external CompactPCI slots for functional module extension;
Integrated Interfaces: 1×Gigabit Ethernet port (compliant with IEEE 802.3), multiple USB 2.0 ports, RS-232/RS-485 serial ports; Video Output: Integrated VGA interface for industrial display; H40G(G) Module: Integrated high-speed I/O module, supporting 40Gbps data transmission for high-bandwidth applications.
3. Electrical Specifications
3.1 Power Supply Parameters
Input Power Supply: +3.3V ±5% DC, +5V ±5% DC, ±12V ±5% DC (compliant with CompactPCI power standard); Typical Current Consumption: +3.3V@1500mA Max, +5V@800mA Max, ±12V@400mA Max;
Power Consumption: ≤30W (Full Load Mode); Power Protection: Over-voltage, Under-voltage, Over-current and Short-Circuit Protection; Ripple Requirement: VPP≤50mV@20MBW for 3.3V, VPP≤100mV@20MBW for 5V.
3.2 Signal & Safety Characteristics
Signal Isolation: Serial ports and digital I/O signals with optical isolation protection; ESD Protection: ±15kV (Air Gap), ±8kV (Contact) per IEC 61000-4-2 standard;
Safety Compliance: IEC 61010-1, UL 61010-1; Emission Standard: EN 55032 Class A; Immunity Standard: EN 55035, IEC 61000-4 Series.
