1 PCS NEW Siemens SONAR-BERO Ultrasonic Sensor 3RG6176-6GG00 #LYQ007
1 PCS NEW Siemens SONAR-BERO Ultrasonic Sensor 3RG6176-6GG00 #LYQ007
| Parameter | Technical Specifications |
|---|---|
| Product Type | Ultrasonic proximity sensor (SONAR-BERO) |
| Sensing Range | 800 ... 10000 mm (80 cm ... 1000 cm) |
| Setting Range | 800 ... 10000 mm |
| Standard Target | 100 x 100 mm |
| Differential Travel (H) | 80 mm |
| Repeat Accuracy (R) | ± 15 mm |
| Ultrasonic Frequency | 60 kHz |
| Switching Frequency | 0.5 Hz |
| Response Time | 800 ms |
| Power-On Delay (Tv) | 280 ms |
| Operating Voltage (UB) | 12 ... 30 V DC (including ripple content) |
| No-Load Supply Current (Io) | Max. 75 mA |
| Permissible Ripple | 10 % |
| Output Type | 2 x PNP (normally open) |
| Rated Operational Current (Ie) | Max. 300 mA (NO), Max. 150 mA (NC) |
| Output Voltage Drop | Max. 3 V (at 300 mA) |
| Off-State Current (Ir) | Max. 0.01 mA |
| Short-Circuit Protection | Built-in |
| Overload Protection | Built-in |
| Switching Status Indicator | Yellow LED |
| Housing Material | Crastin; epoxy resin converter surface |
| Connection | M12 connector |
| Degree of Protection | IP65 |
| Operating Ambient Temperature | -25 ... +70 °C |
| Storage Temperature | -40 ... +85 °C |
| Weight | Approx. 150 g |
