1 PCS new Datalogic Matrix 220 380-010 (1.2MP DPM-R 7mm)Decoder #LYQ007
1 PCS new Datalogic Matrix 220 380-010 (1.2MP DPM-R 7mm)Decoder #LYQ007
| Parameter | Specification |
|---|---|
| Model | MATRIX 220 380-010 (1.2MP DPM-R 7mm) |
| Part Number | 937900004 |
| Sensor | 1/3" CMOS global shutter, 1280 x 960 (1.2 MP) |
| Frame Rate | 45 frames/s |
| Optical Focus | Electronic focus control |
| Lens | 7 mm (38.3° horizontal view angle) |
| Reading Range | Min: 40 mm; Max: 400 mm |
| Illumination | DPM-R (Red) with polarizer & diffuser |
| Aiming System | 2 Red Aimer LEDs |
| Protection Class | IP65, IP67 |
| Operating Temp | -10°C to 50°C (14°F to 122°F) |
| Storage Temp | -20°C to 70°C (-4°F to 158°F) |
| Power Supply | 10–30 VDC (non-PoE) |
| Power Consumption | 3.7 W |
| Dimensions | 78 x 47 x 38 mm (connectors at 0°) |
| Weight | 173 g (6.1 oz) |
| Case Material | Aluminum case + plastic window |
| Digital Inputs | 2 opto-coupled, polarity insensitive |
| Digital Outputs | 3 configurable (NPN/PNN/PP), short-circuit protected |
| Connectivity | Ethernet, ID-NET™, PROFINET IO, EtherNet/IP |
| Programming | DL.CODE™ software, X-PRESS™ HMI |
| User Interface | Beeper, push button, 7 LEDs, Green/Red spot |
| Code Capability | 1D/2D codes, DPM (Direct Part Marking)Datalogic |
| Resolution | Down to 2 mils (0.05 mm) |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
