1 PCS new Beckhoff CX5130-0113/000053717 module #LYQ007
1 PCS new Beckhoff CX5130-0113/000053717 module #LYQ007
| Parameter | Specification |
|---|---|
| Model | CX5130-0113/000053717 |
| Processor | Intel Atom® E3827, 1.75 GHz |
| Number of Cores | 2 |
| Main Memory | 4 GB DDR3 RAM (not expandable) |
| Flash Memory | Slot for CFast card and microSD card (cards not included) |
| Persistent Memory | Integrated 1‑second UPS (1 MB on CFast card) |
| Interfaces | 2 x RJ45 10/100/1000 Mbit/s Ethernet, 1 x DVI‑I, 4 x USB 2.0, 1 x optional interface |
| Diagnostics LEDs | 1 x power, 1 x TC status, 1 x flash access, 2 x bus status |
| Clock | Internal battery‑backed clock (battery exchangeable) |
| Operating System | Microsoft Windows Embedded Compact 7, Windows Embedded Standard 7 P, Windows 10 IoT Enterprise LTSB |
| Control Software | TwinCAT 2 runtime, TwinCAT 3 runtime (XAR) |
| I/O Connection | E‑bus or K‑bus, automatic recognition |
| Power Supply | 24 V DC (-15 %/+20 %) |
| E‑bus/K‑bus Current | 2 A |
| Max. Power Consumption | 14 W (20 W with loaded UPS) |
| Dimensions (W x H x D) | 142 mm x 100 mm x 92 mm |
| Weight | Approx. 960 g |
| Operating Temperature | -25 … +60 °C |
| Storage Temperature | -40 … +85 °C |
| Relative Humidity | 95 %, no condensation |
| Vibration/Shock | Conforms to EN 60068‑2‑6 / EN 60068‑2‑27 |
| EMC | Conforms to EN 61000‑6‑2 / EN 61000‑6‑4 |
| Protection Class | IP20 |
| Approvals | CE, UL, ATEX, IECEx |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
