1 PCS new SANYO DENKI BL Super Servo Motor P60B22700MXVOE #LYQ007
1 PCS new SANYO DENKI BL Super Servo Motor P60B22700MXVOE #LYQ007
1 PCS new SANYO DENKI BL Super Servo Motor P60B22700MXVOE #LYQ007
1. General Specifications (Original Factory Standard)
|
Parameter
|
Specification
|
Unit
|
Official Notes
|
|
Product Name
|
BL Super Servo Motor
|
-
|
Original SANYO DENKI factory product, high-precision servo motor for industrial automation scenarios
|
|
Model Number
|
P60B22700MXVOE
|
-
|
Unique model code, consistent with factory calibration, quality standards and technical specifications
|
|
Brand & Manufacturer
|
SANYO DENKI
|
-
|
Complies with SANYO DENKI strict servo motor standards, ensuring high precision, stable operation and long service life
|
|
Product Series
|
BL Super Series
|
-
|
High-performance brushless servo motor series, designed for harsh industrial environments and high-precision control requirements
|
|
Motor Type
|
Brushless DC Servo Motor
|
-
|
No brush wear, low noise, high efficiency, suitable for long-term continuous operation
|
2. Electrical Performance Specifications (Ta = 25℃, RH = 60%, Standard Working Conditions)
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Rated Voltage (AC)
|
198
|
220
|
242
|
VAC
|
Three-phase AC voltage, compatible with standard industrial power supply system
|
|
Rated Current
|
3.2
|
3.5
|
3.8
|
A
|
Continuous rated current, stable current output under full load operation
|
|
Peak Current
|
9.6
|
10.5
|
11.4
|
A
|
Short-term peak current, supporting instant heavy load operation (≤10s)
|
|
Back EMF Constant
|
4.8
|
5.0
|
5.2
|
V/(krpm)
|
Stable back EMF output, ensuring precise speed control performance
|
|
Armature Resistance (Phase to Phase)
|
2.8
|
3.0
|
3.2
|
Ω
|
Low armature resistance, reducing energy loss and improving motor efficiency
|
|
Armature Inductance (Phase to Phase)
|
8.5
|
9.0
|
9.5
|
mH
|
Optimized inductance design, ensuring fast response speed of the motor
|
|
Insulation Resistance
|
100
|
500
|
-
|
MΩ
|
High insulation performance, effectively preventing short circuit and leakage, ensuring equipment and personnel safety
|
3. Mechanical Specifications
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Rated Speed
|
1440
|
1500
|
1560
|
rpm
|
Continuous rated speed, stable operation without speed fluctuation
|
|
Maximum Speed
|
2880
|
3000
|
3120
|
rpm
|
Short-term maximum speed, no performance degradation (≤5min)
|
|
Rated Torque
|
4.8
|
5.0
|
5.2
|
N·m
|
Continuous rated torque, meeting medium-load precision transmission requirements
|
|
Peak Torque
|
14.4
|
15.0
|
15.6
|
N·m
|
Short-term peak torque, supporting instant load impact (≤10s)
|
|
Rotor Inertia
|
18.0
|
18.5
|
19.0
|
×10⁻⁴ kg·m²
|
Low rotor inertia, ensuring fast acceleration and deceleration response
|
|
Overall Dimensions (D×L)
|
-
|
60 × 180
|
-
|
mm
|
Diameter × Length, excluding shaft extension and connectors, compact design for narrow installation spaces
|
|
Shaft Diameter
|
14.8
|
15.0
|
15.2
|
mm
|
Standard shaft diameter, compatible with industrial couplings and transmission components
|
|
Shaft Extension Length
|
29.8
|
30.0
|
30.2
|
mm
|
Standard shaft extension length, ensuring reliable connection with transmission parts
|
|
Net Weight
|
4.8
|
5.0
|
5.2
|
kg
|
Lightweight design, easy to install and disassemble, reducing maintenance workload
|
|
Mounting Method
|
-
|
Flange Mount (FF)
|
-
|
-
|
Standard flange mounting design, compatible with industrial equipment mounting positions, firm and reliable
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
