Rated Output Power    1.8    kW    Continuous operation power at rated conditions
Rated Voltage    200    VAC    3-phase AC, compatible with Sigma-5 series servo drives (SGDV-180A)
Rated Current    10.0    A    RMS value, continuous current at rated power
Peak Current    30.0    A    3 times rated current, 3 seconds maximum duration for overload operation
Rated Frequency    83.3    Hz    Motor rated operation frequency
Brake Voltage    24    VDC    Electromagnetic brake rated voltage, ±10% tolerance
Brake Current    0.3    A    Current consumption of the built-in brake
Insulation Class    F    -    Temperature rise limit: 155°C, suitable for long-term continuous operation
Insulation Resistance    ≥100    MΩ    At 500VDC, between winding and frame
Dielectric Strength    1500    VAC    1 minute test between winding and frame, no breakdown

Specification    Value    Unit    Remarks
Rated Speed    1500    rpm    Continuous rotation speed at rated power
Maximum Speed    3000    rpm    Maximum allowable rotation speed, short-time operation
Rated Torque    11.5    N·m    Torque output at rated speed and power
Peak Torque    34.4    N·m    Maximum torque output for acceleration/deceleration
Rotor Inertia    14.8 × 10⁻⁴    kg·m²    High inertia, suitable for direct connection to large-load mechanical components
Cogging Torque    ≤0.29    N·m    Low cogging torque, ensures smooth low-speed operation
Shaft Diameter    28    mm    Keyed shaft, standard key size: 8×7×30 mm
Shaft Length    60    mm    Total length of the motor shaft extending from the flange
Radial Load Capacity    1177    N    Maximum allowable radial force on the shaft end
Axial Load Capacity    589    N    Maximum allowable axial force on the shaft end
Frame Size (Flange Diameter)    130    mm    JIS standard flange size, easy to install and replace
Overall Dimensions (L×W×H)    315 × 130 × 130    mm    Approximate dimensions, including motor body and brake
Net Weight    23    kg    Approximate weight, including built-in brake  and encoder
