Resolution    2500 PPR (Pulses Per Revolution)    A, A̅, B, B̅ quadrature signals; Z, Z̅ index signal (1 pulse per revolution)
Signal Output    5V DC Differential Line Driver (RS-422 compliant)    4 differential channels (A/A̅, B/B̅, Z/Z̅); 20mA max output current per channel
Signal Phase Shift    90° ±5° between A and B signals    Quadrature encoding for direction detection and position counting
Index Signal (Z)    1 pulse per revolution, 90° phase-aligned with A signal    For zero position reference and homing operations
Maximum Rotational Speed    10,000 RPM (continuous operation)    12,000 RPM peak speed (short-term, ≤ 10 seconds)
Accuracy (Linearity Error)    ±0.05° (max)    Ultra-high precision for CNC and servo positioning
Signal Rise/Fall Time    50ns ±10ns (at 5V, 100Ω load)    Fast signal response for high-speed motion control

Supply Voltage    5V DC ±5%    4.75V ~ 5.25V operating range
Power Consumption    ≤ 1.2W (typical)    Low power draw, suitable for battery-backed systems
Input Current    ≤ 240mA (at 5V DC)    Stable power demand, no voltage sag under load
Output Load Capacity    Up to 100Ω differential load    Supports long cable runs (up to 300m with shielded cable)
Electrical Isolation    2500V AC (1 minute, signal to ground)    Prevents ground loop interference and voltage transients
Reverse Polarity Protection    Yes    Built-in protection against incorrect power wiring
Short Circuit Protection    Yes    Output channels protected against short circuits to ground

 1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.

 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
