General Information
- Part Number: Z23030011

- Product Name: Industrial Area Scan Camera

- Product Series: STAUBLI Industrial Vision Series

- Product Type: 3.2MP Color Industrial Camera, Global Shutter CMOS

- Core Application: Suitable for precision inspection, assembly positioning, quality control, and automation vision systems in automotive, electronics, and machinery manufacturing industries

- Core Technology: GigE Vision Protocol, High Dynamic Range (HDR) imaging, Anti-noise Signal Processing

2. Electrical Specifications
Input Power
- Power Supply: 12V DC ±10%, Supports PoE (Power over Ethernet) IEEE 802.3af

- Power Consumption: Typical ＜3.5W @ 12V DC; ＜4.0W (PoE Mode)

- Power Connector: Integrated with I/O Connector (6-pin Hirose Connector)

- Power Protection: Reverse Polarity Protection, Over-Voltage Protection (15V DC Max)

- Auxiliary Function: Power Status Monitoring via Software

 Output Parameters
- Sensor Type: 1/1.8” Color CMOS, Global Shutter

- Resolution: 2048 × 1536 Pixels (3.2 Megapixels)

- Pixel Size: 3.45 μm × 3.45 μm

- Maximum Frame Rate: 37.5 fps @ Full Resolution

- Dynamic Range: ≥73 dB; Signal-to-Noise Ratio (SNR): ≥40 dB

- Exposure Time: Ultra-short Mode (1 μs ~ 14 μs); Normal Mode (15 μs ~ 10 sec)

Gain Range: 0 dB ~ 20 dB (Adjustable in 0.1 dB Steps)
