Part Number: TCPW110ACE; Product Name: TOSHIBA TCPW110ACE Power Module; Product Series: TOSHIBA Industrial Grade Switching Power Modules, specialized for medium-power industrial applications.
Brand: TOSHIBA Corporation (A global leader in electronic components and industrial equipment, renowned for reliable power semiconductor technologies. The TCPW110ACE integrates advanced switching topology with robust thermal design, delivering stable power supply for industrial control systems.)
Product Status: Industrial-Grade Original Equipment (Factory Tested, RoHS Compliant, Anti-Static Packaging); Product Category: Isolated Switching Power Module, designed for precision power conversion in industrial automation systems.
Core Application: Dedicated to industrial control systems, servo drives, frequency converters, PLCs, and precision electronic equipment requiring stable and efficient power supply. Widely used in manufacturing, robotics, automotive electronics, industrial instrumentation, and power control systems.
Core Features: High conversion efficiency; Isolated input-output design for safety; Compact modular package for space-saving installation; Built-in comprehensive protection functions; Wide input voltage range for global compatibility; Low ripple and noise output; Stable performance under harsh industrial environments.
2. Core Electrical Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Input Parameters
Input Voltage Range: AC 85-265V (Universal Input), DC 106-370V (Optional); Input Frequency: 50/60Hz ±10%; Input Current: 2A (Maximum RMS at 110V AC), 1A (Maximum RMS at 220V AC);
Inrush Current: ≤30A (Peak, Cold Start at 230V AC); Input Power Factor: ≥0.95 (At Full Load, 220V AC Input);
Standby Power Consumption: ≤0.5W (No Load Condition).
2.2 Output Parameters
Rated Output Power: 110W (Continuous Output); Output Voltage: 5V DC (Fixed Output), 12V DC / 24V DC (Optional Configurations);
Output Current: 22A (Maximum Continuous at 5V DC Output), 9.2A (Maximum Continuous at 12V DC Output), 4.6A (Maximum Continuous at 24V DC Output);
Output Ripple & Noise: ≤1% of Rated Output Voltage (Peak-Peak); Voltage Regulation: ±0.5% (Line Regulation), ±1% (Load Regulation);
Conversion Efficiency: ≥92% (At Full Load, Rated Input Voltage); Operating Frequency: 100kHz (Typical Switching Frequency).
