1 PCS USED ABB Touchscreen CP665-WEB A0 #LYQ007
1 PCS USED ABB Touchscreen CP665-WEB A0 #LYQ007
1 PCS USED ABB Touchscreen CP665-WEB A0 #LYQ007
Part Number: CP665-WEB A0; Model: CP665-WEB A0; Product Name: ABB CP665-WEB A0 Industrial Touchscreen HMI; Product Series: ABB CP Series, Web-Enabled Industrial Human-Machine Interface Panel
Brand: ABB (A global leader in power and automation technologies, renowned for its reliable industrial control solutions, advanced engineering capabilities, and comprehensive system integration support. ABB’s HMI products serve key industries including automotive, energy, manufacturing, and infrastructure. The CP665-WEB A0 touchscreen is a 10-inch industrial-grade HMI designed for intuitive operation, real-time data visualization, and seamless connectivity with ABB controllers and third-party industrial systems, featuring web-enabled functionality for remote monitoring and management.)
Product Status: Industrial-Grade Original Equipment (Factory Calibrated, 100% Functional, RoHS & REACH Compliant); Product Category: Industrial Touchscreen HMI, characterized by rugged construction, wide environmental adaptability, and built-in web server for remote access.
Core Application: Compatible with ABB AC500, AC800M controllers and mainstream industrial control platforms (PLC, SCADA systems), widely applied in electric vehicle charging stations, manufacturing assembly lines, energy distribution facilities, and process control workshops. It is particularly suitable for applications requiring 24/7 continuous operation, intuitive status display with color-coded indicators, and remote parameter adjustment.
Core Features: 10-inch high-brightness TFT LCD display with excellent visibility under harsh lighting; Industrial-grade resistive touch technology for reliable operation in dusty environments; Built-in web server for remote monitoring and control via TCP/IP; Seamless integration with ABB proprietary protocols and standard industrial communication protocols; Rugged design resistant to vibration, dust, and electrical interference; Support for color-coded status display and automatic fault diagnosis; Compliance with international industrial safety and EMC standards.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Display Performance Parameters
Panel Specification: Panel Type: Industrial-Grade TFT LCD Panel; Display Size: 10 Inches (Diagonal); Aspect Ratio: 4:3 (Standard); Resolution: 800 × 480 Pixels; Display Colors: 65,536 Colors (16-Bit); Luminance (Brightness): 400 cd/㎡ (Nits), Adjustable from 10% to 100% via software.
Visual Performance: Contrast Ratio: 1000:1 (Typical); Response Time: 12 ms (Rise + Fall); Viewing Angle: Horizontal ±70°, Vertical ±60° (Minimal Color Distortion); Backlight Type: LED Backlight, Service Life: ≥50,000 Hours (Mean Time to Half Brightness); Anti-Glare Coating: Matte Surface to Reduce Reflection in Outdoor and Strong Workshop Lighting.
Touchscreen Performance: Touch Technology: Industrial-Grade Resistive Touchscreen; Touch Accuracy: ±2 Pixels (Full Screen); Touch Response Time: ≤50 ms; Number of Touch Points: 1 Point (Single-Touch Support); Surface Durability: Resistant to Scratches and Light Chemical Cleaners; Touch Activation Force: 50-100 g, Compatible with Gloved Operation.
2.2 Electrical Performance Parameters
Power Supply Requirements: DC Input Voltage: 24V DC (Typical), Voltage Tolerance: -15% ~ +20% (DC20.4V ~ 28.8V); Rated Input Current: 400mA (Normal Operation), 1.0A (Peak, During Startup); Power Consumption: ≤9.6W (Normal Operation), ≤28.8W (Peak Load); Standby Power Consumption: ≤0.8W.
Signal Interfaces: Communication Interface: 1× Ethernet (RJ45, TCP/IP, Built-in Web Server), 2× RS-232/RS-485 (Multi-Protocol: Modbus RTU, ABB Proprietary Protocol); Expansion Interface: 1× USB 2.0 Type A (for Data Transfer/Parameter Backup); Compatibility: Fully Supports ABB Industrial Protocols and Standard Modbus Communication Protocols.
Insulation Performance: Insulation Resistance: ≥100MΩ (500V DC); Dielectric Strength: 1.5kV AC for 1 Minute (Power Circuit to Ground); Isolation: Optical Isolation Between Signal Circuit and Power Circuit (2500V AC, 1 Minute); Overvoltage Withstand: ≥36V DC (Transient).
EMC Performance: ESD Protection: ±8kV (Contact Discharge), ±15kV (Air Discharge) Per IEC 61000-4-2; Surge Protection: ±2kV (Line to Ground) Per IEC 61000-4-5; Fast Transient Immunity: ±2kV (Power Line), ±1kV (Signal Line) Per IEC 61000-4-4; EMI Filter: Built-in Filter, Compliant with EN 61000-6-4 (Industrial Class A); EMC Compliance: EN 55022, EN 55032.
