1 PCS used Elmo Controller G-DCBEL5/100EEAP #LYQ007
1 PCS used Elmo Controller G-DCBEL5/100EEAP #LYQ007
|
Item
|
Specification
|
|
Model Number
|
G-DCBEL5/100EEAP
|
|
Product Name
|
Elmo Industrial Servo Controller
|
|
Product Series
|
Elmo G-DCBEL Series, High-Power DC Servo Controller
|
|
Brand
|
Elmo Motion Control
|
|
Product Status
|
Industrial-Grade Original Equipment, RoHS 2.0 Compliant, CE Certified, UL Listed, IP20 Protection Class
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
Supply Voltage (DC)
|
18
|
48
|
80
|
V DC
|
Stable DC input, ripple voltage ≤ 10%, reverse polarity protection
|
|
Continuous Output Current
|
5
|
7.5
|
10
|
A RMS
|
Continuous operation at 25℃ ambient temperature, derating at high temperature
|
|
Peak Output Current
|
15
|
20
|
30
|
A RMS
|
Duration ≤ 1 second, duty cycle ≤ 10%, for short-term high-load operation
|
|
Output Power
|
90
|
360
|
800
|
W
|
Depends on supply voltage and output current, efficiency ≥ 90%
|
|
Control Mode
|
-
|
Current / Velocity / Position
|
-
|
-
|
Software-configurable, seamless switching between modes
|
|
Current Control Bandwidth
|
1
|
5
|
10
|
kHz
|
High bandwidth for fast current response, low torque ripple
|
|
Velocity Control Range
|
0.1
|
1000
|
5000
|
RPM
|
Precision velocity regulation, error ≤ 0.1% of set value
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
Position Control Resolution
|
1
|
0.1
|
0.01
|
Counts
|
Depends on encoder resolution, support 16-bit to 24-bit encoder input
|
|
Maximum Velocity Command
|
1
|
1000
|
10000
|
RPM
|
Software-limited, compatible with high-speed servo motors
|
|
Acceleration
|
100
|
5000
|
20000
|
RPM/s
|
Adjustable via configuration software, smooth acceleration/deceleration
|
|
Encoder Input
|
1024
|
2048
|
16384
|
Lines/rev
|
Support incremental/absolute encoders, differential signal input, anti-interference design
|
|
Control Cycle
|
0.1
|
1
|
10
|
ms
|
Real-time motion control cycle, software-configurable for different precision requirements
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
