Parameter    Details
Product Model    20BC205A0ANNANA0 (Allen‑Bradley PowerFlex 700 AC Drive)
Input Voltage    3‑phase, 400V AC, 50/60Hz (±10% tolerance)
Output Current    205A (Normal Duty, ND); 164A (Heavy Duty, HD, 90kW)
Output Power    110kW (ND), 90kW (HD)
Output Voltage    0‑400V AC (variable, matches input voltage range)
Max. Output Frequency    Up to 420Hz
Control Mode    24V DC I/O Vector Control (variant C)
Frame Size    Frame 6
Communication    No communication module (variant A)
Mechanical & Environmental Specifications
Parameter    Details
Enclosure    IP20, NEMA/UL Type 1, with Conformal Coating (variant 0)
Operator Interface    HIM (keypad, variant N)
EMC Filter    CE second environment filter (variant A)
Brake Configuration    Brake IGBT Installed (variant N), No internal braking resistor (variant A)
Operating Temperature    0‑40°C (ambient, derate above 40°C)
Storage Temperature    ‑25‑70°C
Relative Humidity    5‑95% (non‑condensing)
Operating Elevation    Up to 1000m (3300ft) without derating
Dimensions (W×H×D)    403.9mm × 850mm × 275.5mm (15.90in × 33.46in × 10.85in)
Performance & Protection
Feature    Specifications
Torque Regulation    Vector control with slip compensation, precise torque control at low speeds
Current Limit    Proactive: 20‑160% of rated output current; Instantaneous: 220‑300% of rated current
Efficiency    97.5% at rated current and nominal line voltage
Overcurrent Protection    Instantaneous overcurrent trip to prevent drive damage
Power Factor    0.95‑1.0 (lagging, over the entire speed range)
