Basic Ratings
Model Series: PowerFlex 700 AC Variable Frequency Drive
Nominal Power: 25 HP (18.5 kW)
Input Voltage/Frequency: 480 V AC, 3‑Phase, 50/60 Hz
Rated Input Current: 37 A
Continuous Output Current: 37 A
Output Voltage: 0‑480 V AC, 3‑Phase (variable, matching input)
Output Frequency Range: 0‑400 Hz (programmable)
Frame Size: 20B
Enclosure & Mechanical
Enclosure Type: NEMA 1 (General Purpose, Indoor)
Cooling Method: Forced Air Cooling
Mounting Type: Floor/Panel Mount (standard)

Approx. Dimensions (H×W×D): 600 × 254 × 356 mm (23.6 × 10 × 14 in)
Control & Operation
Control Modes: V/Hz, Sensorless Vector (standard); Closed‑Loop Vector (optional)
Speed Regulation (Sensorless Vector): ±0.5% of rated speed
Acc/Dec Time: 0.1‑3600 sec (adjustable, separate acceleration/deceleration)
Torque Boost: 0‑30% (manual/auto, low‑speed torque compensation)
Skip Frequencies: Up to 8 programmable points
Programming Interfaces: Local keypad, RSLogix 500/5000, PowerFlex Toolbox
Communication (Key Difference from ANC0)
Built‑in Protocol: EtherNet/IP (ANC1 suffix indicates a specific EtherNet/IP variant, typically with enhanced communication functions or different protocol settings compared to ANC0)
No additional communication modules (factory default)
I/O Interfaces
Digital Inputs: 6 × 24 V DC (configurable)
Digital Outputs: 3 × Relay (2 A @ 240 V AC/30 V DC)
Analog Inputs: 2 × (0‑10 V DC/4‑20 mA, selectable)
Analog Outputs: 1 × (0‑10 V DC/4‑20 mA, selectable)
Protection Features
Overcurrent protection (motor/drive, instantaneous/time‑delayed)
DC bus overvoltage/undervoltage protection
Internal drive & motor overtemperature protection (PTC thermistor input)
Ground fault protection
Motor locked rotor protection
Short circuit protection (200% rated current, momentary)
Input line surge suppression (built‑in)
Environmental Ratings
Operating Temperature: 0°C‑40°C (32°F‑104°F); 1% derate/°C above 40°C (up to 50°C)
Storage Temperature: -40°C‑70°C (-40°F‑158°F)
Relative Humidity: 5%‑95% RH (non‑condensing)
Altitude: Up to 1000 m (3280 ft); 1% derate/100 m above 1000 m (up to 3000 m)
Vibration Resistance: 5‑2000 Hz, 2 g (operational); 5 g (non‑operational)
