1 pc used SHINKAWA VM-5Z2 Power Supply Unit #LYQ007
1 pc used SHINKAWA VM-5Z2 Power Supply Unit #LYQ007
| Item | Specifications |
|---|---|
| Model | VM-5Z2 |
| Type | Power Supply Unit for VM-5 Series Monitor |
| Power Supply Voltage (Spec. 1) | 85 to 264VAC (Conforms to CE marking) |
| Power Supply Voltage (Spec. 2) | 88 to 144VDC (Does not conform to CE marking) |
| Power Supply Voltage (Spec. 3) | 24VDC±10% (Conforms to CE marking) |
| Output | 30VDC, 5A |
| Power Consumption | 135W or less |
| Indicators | +5V, +17V, +24V, -15V, -30V Power OK (Green LED) |
| Alarm Contact Output | System OK (Dry Contact, C Contact) |
| Contact Capacity | 250VAC, 5A |
| Contact Life | 100,000 times or more (rated load) |
| Insulation Resistance | 100MΩ or more at 500VDC (Between power supply & GND, power supply & alarm contact, GND & alarm contact) |
| Dielectric Strength | 2,000VAC, 1 minute (Between power supply & GND) |
| Operating Temperature | 0 to 65°C (32 to 149°F) |
| Storage Temperature | -30 to +85°C (-22 to 185°F) |
| Relative Humidity | 20 to 95% (noncondensing) |
| Material (Panel) | Aluminum (Munsel N-1.0 equivalent) |
| Mass | Max. 3.0kg (Max. 6.6lb) |
| Standards | Conforms to RoHS Directive |
