Power Rating
Input Voltage: 380 V AC, 3‑Phase (Code "A0" = 380 V Class)
Output Current: 140 A
Output Power: 75 kW (100 HP) Normal Duty; 55 kW (75 HP) Heavy Duty (380 V, 50/60 Hz)
Control Mode: V/Hz, Sensorless Vector, Closed‑Loop Vector (optional with encoder feedback); Vector Control with 24 V DC I/O
Enclosure Type: IP20 / NEMA 1 (General Purpose, Indoor Use) with Conformal Coating
Cooling Method: Forced Air Cooling
HIM (Human Interface Module): 3 (LCD Display, Full Numeric Keypad)
Brake Configuration: Brake IGBT (Yes); Drive‑Mounted Brake Resistor (No)
Documentation: Manual Not Included (Code "N" = No Documentation)
Communication Options
Embedded: None (Code "N" = No Communication Module)
Optional: EtherNet/IP, ControlNet, PROFIBUS DP
Emission Class: First Environment CE Filter (Code "N" = Basic Emission Configuration)
Input Frequency: 50/60 Hz
Output Frequency Range: 0 – 400 Hz
Ambient Operating Temperature: -10 °C to 40 °C (14 °F to 104 °F)
Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)

Mounting Type: Panel Mount
Compliance: UL, cUL, CE, RoHS
