1 PCS USED Kollmorgen SERVOSTAR 446M-C / S406M-CA #LYQ007
1 PCS USED Kollmorgen SERVOSTAR 446M-C / S406M-CA #LYQ007
| Parameter | Value |
|---|---|
| Model | SERVOSTAR 446M-C (S406M-CA) |
| Supply Voltage | 3 x 400 VAC ±10%, 50/60 HzKollmorgen |
| DC Bus Link Voltage | 320 ... 560 VDCKollmorgen |
| Rated Output Current (rms) | 6 Arms (3%, @ 8 kHz)Kollmorgen |
| Peak Output Current (max. 5s) | 12 Arms (3%, @ 8 kHz)Kollmorgen |
| Max. Installed Load (S1) | 12 kVAKollmorgen |
| Switching Frequency | 8 kHz (switchable to 16 kHz with power reduction)Kollmorgen |
| Control Modes | Torque, Speed, Position (fully digital)Kollmorgen |
| Current Controller | Digital (space vector PWM, 62.5 µs)Kollmorgen |
| Speed Controller | Freely programmable (62.5 µs or 250 µs)Kollmorgen |
| Position Controller | Integral (250 µs)Kollmorgen |
| Communication Interfaces | CANopen (standard), PROFIBUS DP, SERCOS, EtherCAT (optional)Kollmorgen |
| Digital Inputs | 4 (opto-isolated, 24 VDC, 7 mA)Kollmorgen |
| Digital Outputs | 2 (open-collector, max. 30 VDC, 10 mA) + 1 Relay (BTB/RTO, max. 30 VDC / 42 VAC, 0.5 A)Kollmorgen |
| Analog Input | ±10 V, 14-bit resolution, 20 kΩ input resistanceKollmorgen |
| Encoder Feedback | Resolver, Sine/Cosine, Incremental, SSI, Hiperface, BiSSKollmorgen |
| Auxiliary Voltage | 24 VDC (isolated)Kollmorgen |
| Motor Holding Brake Control | 24 VDC, max. 1.5 AKollmorgen |
| Protection Features | Overvoltage, Short-circuit, Phase-failure, I²t, OvertemperatureKollmorgen |
| Dimensions (H x W x D) | 150 x 300 x 270 mmKollmorgen |
| Weight | Approx. 6.9 kgKollmorgen |
| Protection Class | IP20 (enclosed)Kollmorgen |
| Ambient Temperature | 0 ... 45 °C (operation), -25 ... +55 °C (storage)Kollmorgen |
| Humidity | 5 ... 95% RH, non-condensingKollmorgen |
| Certifications | UL 840, UL 508C, CE (LVD, EMC)Kollmorgen |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
