1 PCS new LEYCON Leybold Vacuum Valve BAV 25 EP AI 24VDC (PN: 215324)#LYQ007
1 PCS new LEYCON Leybold Vacuum Valve BAV 25 EP AI 24VDC (PN: 215324)#LYQ007
| Parameter | Value |
|---|---|
| Product Type | High Vacuum Angle Valve (BAV) |
| Part Number | 215324 |
| Nominal Diameter (DN) | 25 mm |
| Flange Standard | ISO-KF |
| Body Material | Aluminum (AlMgSi) |
| Valve Plate Material | AISI 316L |
| Bellows Material | AISI 316L (1.4404, 1.4435) |
| Actuator Type | Electropneumatic (EP), Single‑acting with closing spring (NC) |
| Control Voltage | 24 VDC |
| Power Consumption | ≤ 2.5 W |
| Leak Rate | ≤ 1·10⁻⁹ mbar·l/s |
| Pressure Range (Valve Open) | 1·10⁻⁸ to 5000 mbar (absolute) |
| Differential Pressure (Opening Direction) | ≤ 2 bar |
| Differential Pressure (Closing Direction) | ≤ 1 bar |
| Opening Differential Pressure | ≤ 2 bar (either direction) |
| Opening Time (at 4 bar pneumatic) | < 120 ms |
| Closing Time (at 8 bar pneumatic) | < 210 ms |
| Molecular Flow Conductance | 14 l/s |
| Weight | 0.36 kg |
| Max. Operating Temperature | 0 to 120 °C (aluminum body) |
| Cycle Life | 20,000 cycles (at 80 °C, Δp = 1 bar) |
| Protection Class | IP50 |
