1 PCS used FOXBORO 875CR‑J1F #LYQ007
1 PCS used FOXBORO 875CR‑J1F #LYQ007
| Parameter Category | Parameter | Value |
|---|---|---|
| Product Identification | Model | 875CR‑J1F |
| Product Type | Intelligent Contacting Conductivity/Resistivity Analyzer | |
| Manufacturer | Foxboro (Invensys/Schneider Electric) | |
| Power Supply | Rated Voltage | 100/120/220/240 V AC, 24 V AC (select via model code) |
| Rated Frequency | 50/60 Hz ±1% | |
| Power Consumption | Max 15 W | |
| Measurement | Primary Measurement Accuracy | ±0.25% of full scale (temp‑compensated, 6 months) |
| Analog Output Accuracy | ±0.05% of full scale | |
| Digital Output Accuracy | ±0.1% of full scale | |
| Resistivity System Accuracy | ±1.06% rms (20–60°C) | |
| Conductivity Ranges (Temp‑Compensated) | 0–1 µS/cm to 0–20 mS/cm (cell factor dependent) | |
| Absolute Conductivity Ranges | 5× higher than compensated (reduced accuracy) | |
| Resistivity Ranges | 0.2 kΩ·cm to 20 MΩ·cm (cell factor dependent) | |
| Measurement Units | µS/cm, mS/cm, S/m, mS/m, kΩ·cm, MΩ·cm, %, °C/°F, mA, ppm/ppt, g/L, oz/gal | |
| Damping | Adjustable: None, 5, 10, 20, 40, 120 s | |
| Temperature Measurement | Sensor Types | 2‑/3‑wire 100 Ω Pt RTD; 2‑wire 100 kΩ Thermistor; 2‑/3‑wire 1000 Ω Pt RTD |
| Temp Range (RTD) | −20 to +200°C (−4 to +392°F) | |
| Temp Range (Thermistor) | −20 to +120°C (−4 to +248°F) | |
| Temp Accuracy (1000 Ω 3‑wire Pt RTD) | ±0.03°C | |
| Outputs | Analog Outputs | Dual isolated 4–20 mA (configurable; #2 disabled with HART) |
| Output Range | 3.8 to 20.5 mA DC (hold mode) | |
| Max Load | 800 Ω | |
| Alarm Relays | 2× Form C contacts; 0.5 A @ 24 V DC; 5 A @ 240 V AC (non‑inductive) | |
| Digital Communication | Standard | RS‑232C (remote config/calibration) |
| Optional | HART (future: FOUNDATION fieldbus, DeviceNet, Profibus PA, FoxCom) | |
| Digital Inputs | Quantity | 4× (PLC compatible; +4.5 V / −20 V powered by analyzer) |
| Logic | High: 2.7–10 V; Low: ≤0.8 V or open | |
| Enclosure & Environmental | Panel Mount | NEMA 1 (front with gasket: NEMA 4X/IP65) |
| Field Mount | Die‑cast aluminum; NEMA 4X/CSA 4X/IEC IP65 | |
| Vibration | 1 g (10 m/s², 5–200 Hz); 0.25 g (2.5 m/s², 5–200 Hz) | |
| Pollution Degree | 3 (ANSI/ISA S82.01) | |
| Overvoltage Category | II (ANSI/ISA S82.01) | |
| Operating Temp | −20 to +55°C (field); −10 to +45°C (panel) | |
| Storage Temp | −40 to +70°C | |
| Safety & Approvals | ATEX | Zone 2; II 3 G; EEx nC IIC; T4 |
| CSA | Class I, Div 2, Gr A–D; Class II, Div 2, Gr F–G; T4 | |
| FM | Class I, Div 2, Gr A–D; Class II, Div 2, Gr F–G; T4 | |
| Physical | Dimensions | Refer to dimensional drawing (field/panel mount variants) |
| Weight | Field: ~3.6 kg; Panel: ~1.4 kg (typical) | |
| Compliance | Standards | USP23/24; ISO/GMP (history log for validation) |
