1 PCS used EtherWAN EX94008-00-1-A Industrial Switch #LYQ007
1 PCS used EtherWAN EX94008-00-1-A Industrial Switch #LYQ007
| Parameter | Specification |
|---|---|
| Model | EX94008-00-1-A |
| Product Type | Hardened Unmanaged Fast Ethernet Switch |
| Ports | 8 x 10/100BASE-TX (RJ45) |
| Switching Method | Store-and-Forward |
| MAC Address Table | 2,048 entries |
| Buffer Memory | 768 KB |
| Data Transfer Rate | 10/100 Mbps, Full/Half Duplex Auto-Negotiation |
| Auto Features | Auto MDI/MDIX, Auto-negotiation |
| QoS | IEEE 802.1p Class of Service (CoS) |
| Broadcast Storm Protection | DIP Switch Configurable |
| Power Input | 12–48 VDC Redundant Power Input |
| Power Consumption | < 5W |
| Relay Alarm | Power Failure, Port Link Down (Dry Contact Output) |
| Surge Protection | 4 kV (IEC 61000-4-5) |
| Operating Temperature | -40°C to +75°C (-40°F to +167°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5% to 95% (Non-condensing) |
| Vibration | IEC 60068-2-6, 2G peak |
| Shock | IEC 60068-2-27, 15G peak |
| EMC Compliance | IEC 61000-6-2, IEC 61000-6-4 |
| Hazardous Location | Class I, Division 2, ATEX Zone 2 |
| Enclosure | Aluminum Case, IP30 |
| Mounting | DIN-Rail (Kit Included) |
| Dimensions (W x H x D) | 50 x 114 x 70 mm (1.97 x 4.49 x 2.76 in) |
| Weight | 0.62 kg (1.37 lbs) |
| Certifications | CE, FCC, UL 1604, ISA 12.12.01, RoHS |
| Fanless Design | Yes |
| MTBF | > 1,000,000 hours |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
