1 PCS used ABB Control Board 88TV01E GJR2385100R1041 #LYQ007
1 PCS used ABB Control Board 88TV01E GJR2385100R1041 #LYQ007
1 PCS used ABB Control Board 88TV01E GJR2385100R1041 #LYQ007
Part Number: GJR2385100R1041; Model: 88TV01E; Product Name: 88TV01E Series Analog Output Control Board
Brand: ABB (A world-renowned provider of power and automation technologies, leading in industrial control systems, electrical components, and drive solutions. Its products are widely applied in metallurgy, papermaking, energy, and heavy machinery industries.)
Product Status: Original Industrial-Grade Control Board (Compliant with International Industrial Automation Standards); Product Category: 88TV Series Analog Output Modules, belonging to ABB's industrial control accessory family, designed for precise signal conversion and drive control coordination.
Core Application: Specifically compatible with ABB ACS880 Series Low-Voltage AC Drives, suitable for high-precision motion control scenarios such as metallurgical rolling mills, paper machine tension control, conveyor systems, and automated production lines. It realizes analog signal output, drive parameter adjustment, and real-time status feedback to ensure stable and accurate operation of drive systems.
Core Features: High-precision analog output; seamless integration with ACS880 drives; industrial-grade anti-interference performance; compact design for cabinet mounting; LED status indicators for quick fault diagnosis; support for standard industrial control protocols; long-term reliability in harsh industrial environments.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance
Power Supply Parameters: Rated Input Voltage 24V DC (regulated); Voltage Fluctuation Range ±10% of rated voltage; Maximum Input Current 100mA; Power Consumption ≤2.4W (under full-load operation); Reverse Polarity Protection: Built-in, preventing damage from incorrect wiring.
Analog Output Parameters: Number of Output Channels: 4 channels (configurable); Output Signal Type: 4-20mA DC (standard) or 0-10V DC (optional, via parameter setting); Output Accuracy: ±0.1% of full scale; Resolution: 16-bit; Load Capacity: Maximum 500Ω for current output, minimum 10kΩ for voltage output; Response Time ≤10ms (from signal input to stable output).
Signal Isolation: Galvanic Isolation Between Input/Output and Power Supply; Isolation Voltage: 250V AC (duration: 1 minute); Isolation Resistance ≥100MΩ (at 500V DC), effectively suppressing electromagnetic interference.
2.2 Control & Interface Performance
Control Compatibility: Fully compatible with ABB ACS880 Series AC Drives; supports direct torque control (DTC) and speed/torque control modes; realizes synchronous coordination with drive control loops (position control loop 500µs, speed control loop 500µs); supports parameter configuration via drive panel or software.
Communication Interface: Integrated with drive internal bus (compatible with ABB drive communication protocol); supports remote parameter reading/writing and status monitoring via upper-level PLC or HMI; optional RS485 expansion interface (Modbus RTU protocol, baud rate 9600-19200bps).
Control Function: Supports on-the-fly target signal adjustment; provides signal calibration function for output accuracy optimization; compatible with drive safety functions (e.g., STO - Safe Torque Off) for interlocking protection.
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
