1 PCS used CKD Thin Chuck CKA-70CS #LYQ007
1 PCS used CKD Thin Chuck CKA-70CS #LYQ007
|
Item
|
Official Specification
|
|
Model Number
|
CKA-70CS
|
|
Product Name
|
CKD Thin Chuck Module, CKA-70CS
|
|
Brand & Manufacturer
|
CKD Corporation, Japan (Original Factory)
|
|
Product Category
|
Thin Chuck, Pneumatic Chuck Module, Industrial Precision Clamping Component
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Operating Pressure Range
|
0.4
|
0.6
|
0.8
|
MPa
|
Dry, clean compressed air, oil-free or oil-lubricated (optional)
|
|
Air Consumption
|
-
|
1.2
|
1.5
|
L/min (ANR)
|
At 0.6MPa operating pressure, no load
|
|
Clamping Force
|
120
|
150
|
180
|
N
|
At 0.6MPa operating pressure, chuck jaw fully closed
|
|
Unclamping Force
|
100
|
130
|
160
|
N
|
At 0.6MPa operating pressure, chuck jaw fully open
|
|
Response Time (Clamp/Unclamp)
|
≤0.1
|
0.15
|
≤0.2
|
s
|
From air supply to full clamp/unclamp position
|
|
Air Inlet/Outlet Port
|
-
|
Rc1/8
|
-
|
-
|
Standard pipe thread, compatible with CKD quick connectors
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Chuck Diameter
|
-
|
70
|
-
|
mm
|
Outer diameter of the chuck body
|
|
Clamping Stroke
|
0.8
|
1.0
|
1.2
|
mm
|
Single jaw stroke, adjustable within range
|
|
Overall Thickness
|
-
|
28
|
-
|
mm
|
Thin design, suitable for narrow installation space
|
|
Net Weight
|
-
|
0.35
|
-
|
kg
|
Without accessories and connecting pipes
|
|
Chuck Jaw Type
|
-
|
3-Jaw, Centering
|
-
|
-
|
Precision centering, replaceable jaw plates available
|
|
Mounting Method
|
-
|
Flange Mount
|
-
|
-
|
Standard mounting holes, compatible with CNC machine tool spindles
|
|
Material
|
-
|
Aluminum Alloy + Steel
|
-
|
-
|
Lightweight and high strength, surface anti-corrosion treatment
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
