Part Number: TLC511 F SAM; Model: TLC511 F SAM; Product Name: Berger Lahr TLC511 F SAM Stepper Motor Driver; Product Series: Berger Lahr TLC Series, Industrial-Grade 2-Phase Hybrid Stepper Driver (SAM Suffix Denotes Enhanced Signal Acquisition & Motion Control Functionality)
Brand: Berger Lahr (A global leader in motion control systems and stepper technology, now part of the Schneider Electric Group. With profound expertise in precision engineering, Berger Lahr delivers reliable motion solutions for automation, semiconductor, packaging, medical, and material handling industries. The TLC511 F SAM is a high-performance 2-phase stepper driver integrated with advanced signal processing capabilities, designed to achieve ultra-smooth motion and precise positioning for demanding industrial applications.)
Product Status: Industrial-Grade Original Equipment (Factory Calibrated, 100% Functional, RoHS Compliant); Product Category: 2-Phase Hybrid Stepper Motor Driver, engineered to convert digital control signals into accurate motor movement, featuring enhanced microstepping resolution and integrated signal acquisition modules for optimized performance.
Core Application: Exclusively compatible with 2-phase hybrid stepper motors, widely applied in high-precision industrial scenarios including CNC engraving machines, precision dispensing equipment, automated optical inspection (AOI) systems, medical diagnostic devices, semiconductor wafer handlers, and 3D printing equipment. It is particularly suitable for applications requiring ultra-low vibration, high positioning repeatability, and real-time signal feedback under light to medium load conditions.
Core Features: 2-phase drive architecture with enhanced current control; Multi-level microstep resolution (up to 1/128 microstep) for ultra-high positioning accuracy; Integrated SAM (Signal Acquisition Module) for real-time motion feedback and vibration suppression; Advanced PWM current control algorithm to reduce motor noise and heat generation; Comprehensive built-in protection mechanisms; RS-485 communication interface for remote configuration and monitoring; Compact DIN rail-mountable design; Compliance with international industrial EMC and safety standards.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical Performance Parameters
Power Supply Requirements: DC 24V ~ 48V (Wide Voltage Range), Rated Input Current: 4.2A (Typical), Peak Input Current: 9A (10ms Duration); Power Consumption: ≤50W (Normal Operation), ≤80W (Peak Load, Full Current Output).
Motor Output Performance: Output Current Range: 0.8A ~ 5.0A (Adjustable in 0.1A Increments); Motor Phase Resistance: 0.1Ω ~ 4Ω; Motor Phase Inductance: 1mH ~ 25mH; Step Resolution: Configurable via DIP Switch or Software, covering full step (1.8°), half step (0.9°), quarter step (0.45°), eighth step (0.225°), sixteenth step (0.1125°), thirty-second step (0.05625°), sixty-fourth step (0.028125°), and one hundred twenty-eighth step (0.0140625°), compatible with 2-phase hybrid stepper motors with standard step angles.
Control Signal Input: Input Signal Type: TTL Level (5V DC), Pulse/Direction Mode or CW/CCW Mode; Input Impedance: 10kΩ ~ 20kΩ; Signal Response Time: ≤0.5μs; Maximum Pulse Frequency: 300kHz (Supports High-Speed Precision Positioning); SAM Module Input: Supports Analog Feedback Signal (4~20mA / 0~10V) for Real-Time Motion Monitoring.
Insulation Performance: Channel-to-Channel Isolation: 1500V AC (1 Minute); Channel-to-Ground Isolation: 2000V AC (1 Minute); Insulation Resistance: ≥100MΩ (500V DC); Dielectric Strength: 1.8kV AC for 1 Minute (Between Power Circuit and Control Circuit).
2.2 Control & Communication Parameters
Control Modes: Pulse/Direction Control, CW/CCW Control, Microstep Control, Torque Limiting Mode, SAM-Based Adaptive Vibration Control; Built-in Functions: Automatic Current Reduction at Standstill (Energy-Saving), Stall Detection, Overload Warning, Motor Damping, and Real-Time Signal Acquisition & Feedback via SAM Module.
Communication Interface: RS-485 Port (Half-Duplex, Optically Isolated); Communication Protocol: Modbus RTU (Configurable); Data Transmission Rate: 9600~115200 bps (Selectable via Software); Supports Remote Parameter Adjustment, Real-Time Status Monitoring, Fault Diagnosis, Parameter Backup/Restore, and SAM Module Data Reading.
EMC Performance: ESD Protection: ±8kV (Contact), ±15kV (Air) Per IEC 61000-4-2; Surge Protection: ±1.5kV (Line to Ground) Per IEC 61000-4-5; EMI Filter: Built-in High-Performance Filter, Compliant with EN 61000-6-4; RFI Suppression: Meets Industrial Class B Standards for Indoor and Semi-Outdoor Applications.
