1 PCS USED B&R Industrial PC 5PC910.SX02-00 #LYQ007
1 PCS USED B&R Industrial PC 5PC910.SX02-00 #LYQ007
1 PCS USED B&R Industrial PC 5PC910.SX02-00 #LYQ007
Part Number: 5PC910.SX02-00; Model: 5PC910.SX02-00; Product Name: B&R Industrial Personal Computer
Brand: B&R (A Global Leader in Industrial Automation, Specializing in PC-Based Control Systems and Automation Solutions)
Product Status: Mature Product (In Stock for Industrial Upgrade & System Integration); Product Category: PC-Based Industrial Controller, Designed for High-Performance Automation Applications
Core Application: Specifically developed for complex industrial automation scenarios, including motion control, process control, machine vision integration, and real-time data processing. Widely applied in automotive manufacturing, packaging machinery, printing equipment, robotics, and semiconductor production lines.
Core Features: High-Performance Multi-Core Processor; Industrial-Grade Stability & Durability; Rich I/O Expansion Interfaces; Support for Real-Time Operating Systems; Fan-Cooled Thermal Management; Compact Design for Cabinet Installation; Compatibility with B&R Automation Software Suite.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Processor & Memory Parameters
Processor Model: Intel Core i3-9100; Core Count: 4 Cores; Thread Count: 4 Threads; Base Frequency: 3.6GHz, Turbo Boost Frequency: Up to 4.2GHz;
Memory Type: DDR4-2400; Maximum Memory Capacity: 64GB; Memory Channels: 2; Memory Bandwidth: Up to 37.5GB/s; Support for ECC Memory: Yes;
Storage Interface: SATA III (6Gbps) x 2, M.2 NVMe Slot x 1; Recommended Storage: Industrial SSD (32GB-1TB) for Vibration Resistance & Long Service Life;
Graphics Performance: Integrated Intel UHD Graphics 630; Maximum Resolution: 4096x2304 @ 60Hz; Support for Multi-Display Output: Yes (DVI-D, DisplayPort).
2.2 I/O Interface Parameters
Ethernet Ports: Gigabit Ethernet (RJ45) x 2 (Support for TCP/IP, PROFINET, Ethernet/IP); USB Ports: USB 3.2 Gen1 x 4, USB 2.0 x 2 (Front x 2, Rear x 4);
Serial Ports: RS232/RS485 (Configurable) x 2; Expansion Slots: PCIe x16 x 1, PCIe x4 x 1, PCI x 1; Video Interfaces: DVI-D x 1, DisplayPort x 1;
Audio Interface: Line-In/Line-Out x 1; Digital I/O: 8-channel Digital Input, 4-channel Digital Output (Optically Isolated); Real-Time Clock: With Battery Backup (Minimum 5 Years Service Life).
3. Hardware Configuration & Mechanical Parameters
3.1 Hardware Configuration
Cooling System: 2 x 80mm Industrial-Grade Brushless Fans (Temperature-Controlled Speed, 1800rpm - 4200rpm); Indicator Lights: Power Indicator (Green), Fault Indicator (Red), HDD Activity Indicator (Yellow);
Power Supply: 100-240V AC ±10%, 50/60Hz, 250W Industrial-Grade Power Supply (Redundant Power Supply Optional); Battery Backup: 3.6V Lithium Battery (For RTC & Configuration Storage).
3.2 Mechanical & Installation Parameters
Dimensions (W × H × D): 482.6mm × 132mm × 350mm (19-inch Rack-Mount, 3U Height); Mounting Type: 19-inch Standard Rack Mount (3U) or Wall-Mount (Optional Bracket);
Weight: ≤8.5kg (Net Weight); Housing Material: Heavy-Duty Steel (Anti-Vibration, Anti-EMI); Protection Grade: IP20 (Indoor Cabinet Installation); Panel Material: Aluminum Alloy (Heat Dissipation).
4. Environmental & Reliability Specifications
4.1 Environmental Parameters
Operating Temperature: 0℃ ~ +50℃; Storage Temperature: -20℃ ~ +60℃;
Relative Humidity: 5% ~ 95% (Non-Condensing, At 40℃); Vibration Resistance: 5Hz ~ 500Hz, 0.3g rms (X/Y/Z Axes, Continuous Operation) Per IEC 60068-2-6;
Shock Resistance: 15g (11ms, Half-Sine Wave, X/Y/Z Axes) Per IEC 60068-2-27; Altitude: ≤2000m (No Derating Required); EMC Compliance: EN 55032 Class B (Electromagnetic Emission), EN 61000-4 Series (Electromagnetic Immunity).
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
