1 PCS new Danfoss 027H2180 ICM25‑A Function Module
1 PCS new Danfoss 027H2180 ICM25‑A Function Module
| Parameter | Value |
|---|---|
| Product Code | 027H2180 |
| Model | ICM 25‑A |
| Product Type | Function Module |
| Body Material | Steel |
| Kv Value | 6 m³/h |
| Cv Value | 7 gal/min |
| Open/Close Time | 7 s |
| Max. Working Pressure | 65 bar / 943 psig |
| Max. Operating Pressure Differential (MaxOPD) | 52 bar / 702 psig |
| Inlet Connection Size | 25 mm |
| Outlet Connection Size | 25 mm |
| Connection Type | Socket Weld |
| Manual Operation | Via ICAD setting / Multifunction tool |
| Net Weight | 1.786 kg |
| Gross Weight | 1.82 kg |
| Volume | 3.329 L |
| EAN | 5702428237635 |
| Compatible Valves | ICV 25 |
| Compatible Refrigerants | R1234ze(E), R134a, R22, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R409A, R410A, R421A, R502, R507, R717, R744 |
| Actuator System | ICAD motor, magnet coupling |
| Temperature Range | -60 °C to +120 °C |
| Packing | Single pack |
| Included Parts | Bolts / O‑ring, Seat / O‑ring |
| EU RoHS Compliance | Out of scope |
