1 PCS new Hirschmann RS30-0802O0ZZSDAEHH07.1.01 Switch #LYQ007
1 PCS new Hirschmann RS30-0802O0ZZSDAEHH07.1.01 Switch #LYQ007
| Parameter | Value |
|---|---|
| Product Model | RS30-0802O0ZZSDAEHH07.1.01 |
| Product Type | Compact OpenRail Managed Industrial Ethernet Switch |
| Port Configuration | 8 × 10/100BASE-TX (RJ45); 2 × Gigabit SFP Slots (Uplink 1); 2 × 100 Mbps SFP Slots (Uplink 2) |
| Switching Capacity | Store-and-forward switching; Layer 2 Enhanced |
| Power Supply | Redundant: 9.6–60 V DC / 18–30 V AC; 24 V DC typical |
| Current Consumption | 320 mA @ 24 V DC; 172 mA @ 48 V DC |
| Power Consumption | 8.3 W (28.4 Btu/h) @ 24 V DC (2×FX ports) |
| Operating Temperature | 0 °C to +60 °C (Standard) |
| Storage/Transport Temp | -40 °C to +70 °C |
| Humidity | 10%–95% (non-condensing) |
| Dimensions (W×H×D) | 74 mm × 131 mm × 111 mm |
| Weight | 410 g (14.46 oz) |
| Mounting | DIN Rail Mount |
| Protection Class | IP20 |
| MTBF | 52.7 years (MIL-HDBK-217F) |
| Cooling | Fanless design |
| Management | Web UI, CLI, Telnet, SNMP v1/v2/v3, HiVision, TFTP/HTTP |
| Redundancy | HIPER-Ring (reconfig < 0.3s), MRP, RSTP, Redundant Power |
| Security | Port Security, SNMPv3, VLAN (802.1Q), GVRP |
| QoS | 4 Priority Classes, 802.1p, TOS/DSCP |
| Industrial Protocols | PROFINET, EtherNet/IP, IEEE 1588 (PTP), SNTP |
| Diagnostics | LEDs, Syslog, RMON, Port Mirroring, SFP Diagnostics |
| Shock Resistance | IEC 60068-2-27: 15 g, 11 ms, 18 shocks |
| Vibration Resistance | IEC 60068-2-6: 1 mm (2–13.2 Hz); 0.7 g (13.2–100 Hz) |
| EMC Immunity | EN 61000-4-2/-3/-4/-5/-6; FCC Class A; EN 55022 Class A |
| Certifications | cUL 508, cUL 1604 Class 1 Div 2, CE, FCC |
| Firmware Version | HH07.1.01 |
